Description
- 1/2.8” Sony Exmor R 2 megapixel CMOS sensor
- H.265 / H.264 / MJPEG compression format
- Digital resolution: 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720) D1 (704x576), CIF (352×288)
- Main stream: 1080P, 1.3MP, 720P (1~50/60 fps)
- Sub stream 1: D1, CIF (1~25/30 fps)
- Sub stream 2: 1080P, 1.3MP, 720P, D1, CIF (1~25/30 fps)
- Day/night mode with removable mechanical filter
- Minimum illumination: 0.005 lux F1.6 color / 0.0005 lux F1.6 B/W
- 25X optical zoom: 4.8 ~ 120 mm
- 16X digital zoom
- 5 configurations white balance
- Automatic and manual gain control
- Backlight compensation (BLC, HLC)
- Real WDR (120 dB)
- 2D and 3D noise reduction
- 24 masking zones
- Autotracking
- Intelligent video detection functions: line crossing, intrusion, abandoned/lost object detection, face detection
- Horizontal positioning: 0° ~ 360° continuous
- Vertical positioning: -0° ~ 90°, 180° autoflip
- Manual speed: 0.1° ~ 350°/sec. (H), 0.1° ~ 250°/sec. (V)
- Preset speed: 500°/sec. (H), 500°/sec. (V)
- 300 DH-SD presets
- 5 patterns, 8 rounds, Auto Pan, Auto Scan
- 3D intelligent positioning (DH-SD protocol)
- 1 audio input / 1 output
- 2 alarm inputs / 1 output
- MicroSD card slot up to 128GB (card not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x
- Compatible with ONVIF, PSIA, CGI
- Up to 20 users
- Power supply: 24V AC / 1.5A (13W), adapter included
- Supports PoE+
- Operating temperature from -30°C ~ +60°C
- Humidity: <90%
- IK10 vandal protection
- Dimensions: Ø198 x 177 mm
- Weight: 2.2 kg
