Description
Technical Specifications
- 1/2.8" CMOS sensor
- Maximum resolution 1080P (1920×1080)
- Automatic day/night switching by ICR
- Minimum illumination 0.004 lux in color at F2.4
- Minimum illumination 0.0004 lux in B/W at F2.4
- 2.8 mm fixed lens
- M12 mount
- Maximum aperture F2.5
- Angle of view 110° horizontal, 59° vertical, 130° diagonal
- Minimum focusing distance 0.5 m
Video
- CVI: 1080P@25 fps and 720P@25/50 fps in PAL
- CVI: 1080P@30 fps and 720P@30/60 fps in NTSC
- AHD: 1080P@25 fps and 720P@25 fps in PAL
- AHD: 1080P@30 fps and 720P@30 fps in NTSC
- TVI: 1080P@25 fps and 720P@25 fps in PAL
- TVI: 1080P@30 fps and 720P@30 fps in NTSC
- CVBS: 960H in PAL and NTSC
- Resolutions 1080P (1920×1080), 720P (1280×720) and 960H (704×576/704×480)
- Video output switchable CVI, TVI, AHD, and CVBS via BNC port
Features
- BLC, HLC, and 120 dB True WDR
- Automatic and manual white balance
- Automatic and manual gain control
- 3D NR noise reduction
- Smart IR
- Electronic defogging
- 4X digital zoom
- Mirror off/on
- Privacy mask off/on
- Multilingual OSD
Audio
- 1 audio input via RCA port for audio pickup
- Audio over coaxial
Communication Interface
- 1 BNC port for CVI, TVI, AHD, and CVBS video output
Power Supply
- 12V DC ±30% power supply
- Maximum power consumption 2.11 W
Environment
- Operating temperature -30°C to +60°C (-30°F to +60°F)
- Operating humidity less than 95% non-condensing
- Storage temperature -30°C to +60°C (-30°F to +60°F)
- Storage humidity less than 95% non-condensing
Physical Characteristics
- Full metal casing
- Ceiling or flat surface installation
- Dimensions 43.5 mm × 36.2 mm × 29.5 mm
- Net weight 0.04 kg
- Gross weight 0.14 kg
Contents
- Dahua 4-in-1 Miniature Camera DAHUA-5210 (DH-HAC-HUM3201BP-0280B-S2)
Certifications and Standards
- CE: EN55032, EN55024, EN50130-4, and EN60950-1
- FCC: CFR 47 FCC Part 15 subpart B and ANSI C63.4-2014
- UL: UL60950-1 and CAN/CSA C22.2 No.60950-1
