Description
- 1/1.8" CMOS sensor with a maximum resolution of 2688 × 1520
- 2.8mm fixed lens (F1.0)
- Viewing angle: 111° (H), 60° (V), 135° (D)
- Day/night mode with ICR filter
- 0.0005 lux (color) / 0.0004 lux (B/W) / 0 lux with IR or white light
- IR illumination and white light up to 30 m
- H.265, H.264 and MJPEG (sub-stream) video compression
- Smart Codec: Smart H.265+ / Smart H.264+
- AI H.265 / AI H.264 intelligent encoding
- Supported resolutions: 4MP (2688 × 1520 / 2560 × 1440), 3MP (2304 × 1296), 1080P (1920 × 1080), 720P (1280 × 720), D1 (704 × 576 / 704 × 480), VGA (640 × 480), CIF (352 × 288 / 352 × 240)
- Stream 1: 4MP (1~30 fps)
- Stream 2: 1080P (1~30 fps)
- Image functions: Digital WDR, BLC, HLC, 3D NR, ROI, rotation, LDC
- Privacy: 8 configurable masks
- Smart Video Functions:
- SMD 4.0
- Perimeter protection: line crossing and intrusion with person and vehicle classification
- AcuPick: intelligent target search
- AI SSA: automatic image adjustment based on the scene
- Video Analysis Event Alarms:
- Motion, tampering, scene change, audio, missing SD, SD error, IP conflict, intrusion, line crossing, light intensity, network failure, illegal access, digital input, security exception.
- Two-way audio: 1 RCA input and 1 RCA output + built-in microphone and speaker
- Active deterrence: red/blue strobe light and siren with customizable audio
- MicroSD slot up to 512 GB (card not included)
- Network interface: RJ-45 10/100 Base-T
- Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, SNMP, P2P
- ONVIF (Profile S/G/T), CGI support
- Software: Smart PSS Lite, DSS, DMSS, DoLynk Care
- Mobile clients: Android / iOS
- Power supply: 12 VDC or PoE 802.3af
- Maximum power consumption: 7.4 W (12 VDC) / 8.7 W (PoE)
- Operating temperature: -40°C to +60°C (-40°F to +60°F)
- Humidity: ≤95%.
- IP67 protection
- Metal casing
- Dimensions: Ø122 × 116.1 mm
- Net weight: 0.8 kg
- Gross weight: 1.0 kg
- 3AXIS: 0°~360° (PAN), 0°~78° (TILT), 0°~360° (Rotation)
- Certifications: CE-LVD, CE-EMC
