Description
- 1/2.7" CMOS sensor with a maximum resolution of 2960 × 1668
- 2.8 mm fixed lens (F1.0)
- Viewing angle: 111.0° (H), 58.5° (V), 136.0° (D)
- ICR filter with day/night mode
- 0.006 lux (color) / 0.0006 lux (B/W) / 0 lux with IR or white light
- Smart Dual Light with IR and white light up to 30 m
- Video compression: H.265 / H.264 / MJPEG (substream)
- Smart Codec: Smart H.265+ / Smart H.264+
- Resolutions: 5MP (2960×1668), 4MP, 3MP, 1080P, 720P, D1, VGA, CIF
- Stream 1: 2960×1668 (1~20 fps) / 2688×1520 (1~25/30 fps)
- Stream 2: 704×576, 704×480 (1~25/30 fps)
- Image functions: 120 dB WDR, BLC, HLC, 3D NR, ROI, rotation, mirror, privacy mask (4 zones)
- Smart auto-illumination between infrared and white light
- Smart functions:
- Perimeter protection: line crossing and intrusion with human/vehicle classification.
- SMD Plus
- Smart search with Dahua NVR
- Alarms: motion detection, video tampering, audio, scene change, SD failure, network failure, IP conflict, illegal access, and voltage.
- Integrated sound and light alarm
- Two-way audio: built-in microphone and speaker
- MicroSD slot up to 256 GB (card not included)
- Network interface: RJ-45 (10/100 Base-T)
- Protocols: IPv4/IPv6, HTTP, TCP, UDP, RTSP, FTP, SMTP, DHCP, DNS, SNMP, P2P, ONVIF (S/G/T), CGI
- Supported software: DSS, Smart PSS Lite, DMSS
- Mobile clients: Android / iOS
- Power supply: 12 VDC or PoE (802.3af)
- Maximum power consumption: 8.8 W (12 VDC) / 10.4 W (PoE); standby: 2.2 W / 2.9 W
- Operating temperature: -40°C to +60°C (-40°F to +60°F)
- Humidity: ≤95% (non-condensing)
- IP67 protection
- Casing: metal core with plastic cover
- Dimensions: 103.5 × Ø109.9 mm
- Net weight: 390 g
- Gross weight: 570 g
- Certifications: CE-LVD, CE-EMC
