Description
- 1/2.7" CMOS sensor with a maximum resolution of 2960 × 1688
- 2.8mm fixed lens (F1.0)
- Viewing angle: 111.0° (H), 58.5° (V), 136.0° (D)
- Day/night mode with ICR filter
- 0.006 lux (Color) / 0.0006 lux (B/W) / 0 lux with IR or white light
- IR and white light illumination up to 30 m
- H.265, H.264, and MJPEG video compression (sub-stream only)
- Smart Codec: Smart H.265+ / Smart H.264+
- Resolution: 5MP (2960 × 1668), 4.6MP (2880 × 1620), 4MP (2688 × 1520), 3MP (2048 × 1536 / 2304 × 1296), 1080P (1920 × 1080), 1.3MP (1280 × 960), 720P (1280 × 720), D1 (704 × 576 / 704 × 480), VGA (640 × 480), CIF (352 × 288 / 352 × 240)
- Stream 1: 5MP (1~20 fps), 4MP (1~25/30 fps)
- Stream 2: D1 (1~25/30 fps)
- Image functions: WDR 120 dB, BLC, HLC, 3D NR, ROI, Rotation, LDC, Mirroring
- Privacy: 4 configurable masks
- Smart video functions:
- SMD Plus
- Perimeter protection: line crossing and intrusion with human and vehicle detection
- Video analysis event alarms:
- Motion detection, video tampering, audio, intrusion, line crossing, network anomalies, voltage, SD location, SMD, security exception
- Active deterrence with flashing white light and customizable voice or sound messages
- Two-way audio: built-in microphone and speaker
- MicroSD slot up to 256 GB (card not included)
- Metal casing
- IP67 protection
- Power supply: 12 VDC ±30 % or 802.3af PoE
- Maximum power consumption: 11.6 W (12 VDC) / 13.5 W (PoE)
- Network interface: RJ-45 (10/100 Base-T)
- Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, Bonjour, P2P, Auto-register
- ONVIF (profile S/G/T), CGI support
- Software: Smart PSS Lite, DSS, DMSS
- Mobile clients: Android / iOS
- Operating temperature: -40°C to +60°C (-40°F to +60°F)
- Operating humidity: ≤95 % (non-condensing)
- Storage temperature: -40°C to +60°C (-40°F to +60°F)
- Storage humidity: ≤95 % (non-condensing)
- Dimensions: 197.9 × 80.2 × 76.2 mm
- Net weight: 0.54 kg / Gross weight: 0.68 kg
- 3AXIS: 0°~360° (PAN), 0°~90° (TILT), 0°~360° (Rotation)
- Certifications: CE-LVD, CE-EMC
