Description
- 1/2.7" CMOS sensor with a maximum resolution of 2880 × 1620
- Fixed 2.8mm lens (F1.6)
- Viewing angle: 104° (H), 56° (V), 124° (D)
- ICR filter with day/night mode
- 0.007 lux (color) / 0.0007 lux (B/W) / 0 lux with IR or white light
- Smart Dual LightIR and white light up to 30 m
- Video compression: H.265 / H.264B / H.264H / MJPEG (sub-stream)
- Resolutions: 5MP (2880×1620), 4MP, 3MP, 1080P, 720P, D1, VGA, CIF
- Stream 1: 2880×1620 (1~25/30 fps)
- Stream 2: 640×360 (1~25/30 fps)
- Image functions: DWDR, 0°/180° rotation, motion detection (4 zones), automatic day/night switching.
- Smart functions:
- Human detection
- Vehicle detection
- Two-way audio: built-in microphone and speaker
- MicroSD slot up to 256 GB (card not included)
- Network:
- RJ-45 interface (10/100 Base-T)
- Wi-Fi 6 (802.11b/g/n/ax, 2.4 GHz, EIRP ≤20 dBm)
- Bluetooth pairing
- ONVIF (Profiles S, G, T), CGI
- Compatible software: Smart PSS Lite, DSS, DMSS
- Mobile clients: Android / iOS
- Power supply: 12 VDC
- Maximum power consumption: 6.9 W (12 VDC); standby: 2.4 W
- Operating temperature: -30°C to +50°C (-30°F to +50°F)
- Humidity: ≤95% (non-condensing)
- IP67 protection
- Metal and plastic housing
- Dimensions: 172.4 × 83.3 × 75.0 mm
- Net weight: 0.3 kg
- Certification: CE
