Description
- 2 MP CMOS Sensor
- Maximum Resolution: 1920 × 1080
- Frames per second:
- HDCVI: 2MP@25/30 fps
- TVI: 2MP@25/30 fps
- AHD: 2MP@25/30 fps
- CVBS: 960H
- Fixed Lens: 2.8 mm (F1.0)
- Viewing Angle: 101.8° (H), 54.4° (V), 122.1° (D)
- Day/Night mode with ICR filter
- Minimum Illumination: 0.005 lux (color) / 0 lux with IR or white light
- Smart Dual Light up to 40 m range
- Image functions: BLC, HLC, WDR 130 dB, 3D NR, automatic white balance, automatic gain control.
- Privacy masks: 8 configurable zones
- Audio: built-in microphone, audio over coaxial in HDCVI
- Video output: selectable HDCVI / TVI / AHD / CVBS
- Power supply: 12 VDC ±30%.
- Maximum power consumption: 7 W (LED on)
- Operating temperature: -40 °C to +60 °C
- Operating humidity:
- Storage temperature: -40 °C to +60 °C.
- Storage humidity: -40 °C to +60 °C:
- IP67 protection
- Metal casing
- Dimensions: 240.8 × 80.2 × 90.7 mm
- Net weight: 0.67 kg
- Gross weight: 0.88 kg
- Installation: wall, pole, or ceiling
- 3AXIS: 0°~360° (Pan), 0°~90° (Tilt), 0°~360° (Rotation)
- Certifications: CE-LVD EN 62368-1, CE-EMC EN 55032 / EN 55035
