Description
- 1/1.8" progressive scan CMOS sensor
- Max resolution: 3840 × 2160 (8MP)
- 2.8 mm fixed lens
- Angle of view: 110° (H), 59° (V), 131° (D)
- Aperture: F1.0
- Day/night mode: Color / B/W, with ICR filter
- Minimum illumination: 0.0008 lux (F1.0)
- Warm light: up to 30 m
- WDR 120 dB, BLC, HLC, 3D NR, ROI, LDC, Smart Illumination
- Compression: H.265+, H.265, H.264+, H.264, MJPEG (sub-stream)
- Stream 1: 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP, 720P (1~20/25/30 fps)
- Stream 2: D1, CIF, VGA (1~25/30 fps)
- Supported resolutions: 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP, 720P, D1, VGA, CIF
- Built-in microphone
- Audio: G.711a/u, PCM, G.726
- Smart detection: line crossing, intrusion (human and vehicle classification)
- Smart functions: SMD Plus, Smart Search (with compatible NVR)
- Events: motion, tampering, audio, SD failure, network disconnection, illegal access, IP conflict, voltage
- Privacy masks: up to 4 zones
- Storage: MicroSD slot up to 256 GB (card not included), FTP/SFTP, NAS
- Network protocols: IPv4/IPv6, HTTP, TCP, UDP, RTP, RTSP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, NTP, UPnP, Multicast, ICMP, IGMP, NFS, PPPoE, P2P, Bonjour
- ONVIF support: S, G, T profiles / CGI
- Network interface: 1 × RJ45 10/100 Mbps
- Clients: Smart PSS Lite, DSS, DMSS
- Supported browsers: IE, Chrome, Firefox
- Security: HTTPS, digest, WSSE, IP/MAC filtering, 802.1x, secure boot/execution/update, X.509, syslog
- Power supply: 12 VDC ±30%, PoE (802.3af)
- Maximum power consumption: 5.6 W (12 VDC), 6.4 W (PoE)
- Operating temperature: -40 °C to +60 °C (-40 °F to +140 °F)
- Storage temperature: -40°C to +60°C (-40°F to +140°F)
- Operating and storage humidity: ≤95% non-condensing
- IP67 protection
- Casing: metal core, plastic cover
- Dimensions: 109.5 × Ø109.9 mm
- Net weight: 0.42 kg
- Gross weight: 0.59 kg
