Description
- 1/2.5" CMOS sensor with a maximum resolution of 4480 × 2512
- 2.8mm fixed lens (F1.6)
- Viewing angle: 112° (H), 58° (V), 136° (D)
- Day/night mode with ICR filter
- 0.008 lux (color) / 0.0008 lux (B/W) / 0 lux with IR or white light
- IR and white light illumination up to 30 m
- H.265, H.264, and MJPEG (sub-stream) video compression
- Smart Codec: Smart H.265+ / Smart H.264+
- Stream 1: 12MP (1~15 fps), 5MP (1~25/30 fps)
- Stream 2: D1 (1~25/30 fps)
- Image functions: Digital WDR, BLC, HLC, 3D NR, ROI, rotation, LDC
- Privacy: 4 configurable masks
- Intelligent video functions:
- SMD Plus
- Perimeter protection: line crossing and intrusion with human and vehicle detection
- Alarm events:
- Motion detection, video tampering, audio, network anomaly, voltage, SD location, intrusion, line crossing, SMD, digital input
- Two-way audio: RCA input/output and built-in microphone
- Alarm: 1 input and 1 output (-AS model)
- MicroSD slot up to 256GB (card not included)
- Network interface: RJ-45 10/100 Base-T
- Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, P2P, Bonjour, Auto Recording
- ONVIF (Profile S/G/T), CGI support
- Software: Smart PSS Lite, DSS, DMSS
- Mobile clients: Android / iOS
- Power supply: 12 VDC ±30% or PoE 802.3af
- Maximum power consumption: 8.7 W (12 VDC) / 10.1 W (PoE)
- Operating temperature: -40 °C to +60 °C (-40 °F to +60 °C)
- Humidity: ≤95% (non-condensing)
- Storage temperature: -40 °C to +60 °C (-40 °F to +60 °F)
- IP67 protection
- Metal casing
- Dimensions: 121.9 × 99.1 mm
- Net weight: 0.51 kg / Gross weight: 0.65 kg
- 3AXIS: 0°~360° (PAN), 0°~78° (TILT), 0°~360° (Rotation)
- Certifications: CE-LVD, CE-EMC
