Description
- 1/2.9" 2-megapixel CMOS sensor
- Compression formats: AI H.265, Smart H.265+, Smart H.264+, H.265, AI H.264, H.264, H.264, MJPEG
- Digital resolution: 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
- Stream 1: 1080P (1~25 fps)
- Stream 2: 1080P (1~25 fps)
- Stream 3: 1080P (1~25 fps)
- Day/night mode with removable mechanical filter (ICR)
- Smart Dual Light: 2 dual-core IR and white light LEDs, 50 meters
- 0.002 lux F1.4 (color), 0.0002 lux F1.4 (B/W), 0 lux IR On
- 2.8 mm fixed lens
- Viewing angle: 100°(H), 55°(V), 117°(D)
- Imaging modes: BLC, HLC, WDR 120dB, SSA, 3D-NR, Mirror, Defogging
- Integrated Lens Distortion Correction (LDC)
- White balance with 6 modes
- Automatic and manual gain control
- 4-zone video sensor, 4 Regions of Interest (ROI) and 8-zone privacy masking
- Perimeter protection with cross-line detection and intrusion detection (both modes support human/vehicle classification)
- SMD 4.0
- Built-in microphone
- MicroSD card slot up to 512 GB (not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP, P2P
- Supports ONVIF (Profile S/G/T/M), CGI, SDK and API
- Up to 20 users
- Remote viewing via IE, Chrome and Firefox browsers
- Smart PSS Lite, DSS, DMSS, DoLynk Care, Smart PSS Lite management software
- Compatible with IOS and Android mobile devices
- Power supply: 12V DC / PoE (802.3af)
- Maximum power consumption: 6.8 W (12V) / 9.1 W (PoE)
- Storage temperature: -40°C ~ +60°C
- Relative storage humidity ≤95% (non-condensing)
- Operating temperature -40°C ~ +60°C (-40°C ~ +60°C)
- Relative operating humidity ≤95% (non-condensing)
- IP67 protection rating
- Metal casing
- Dimensions: 70.5 (L) x 66.4 (H) x 192.7 mm
- Net weight: 610 g
- Gross weight: 770 g
- 3AXIS: 0°~360°(PAN), 0°~90°(TILT), 0°~360°(Rotation)
