Description
- 4 megapixel 1/2.9" CMOS sensor
- Compression formats: AI H.265, Smart H.265+, Smart H.264+, H.265, AI H.264, H.264, MJPEG
- Digital resolution: 4MP (2688x1520), 3.6MP (2560x1440), 3MP (2048x1535, 2304x1296), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
- Stream 1: 4MP (1~25 fps)
- Stream 2: D1 (1~25 fps)
- Stream 3: 1080P (1~25 fps)
- Day/night mode with removable mechanical filter (ICR)
- Smart IR: 3 LEDs, 40 meters
- 0.002 lux F1.6 (color), 0.0002 lux F1.6 (B/W), 0 lux IR On
- Motorized 2.7 ~ 13.5 mm optics
- Viewing angle: 104°~29°(H), 54°~16°(V), 125°~34°(D)
- Image modes: BLC, HLC, WDR 120dB, SSA, 3D-NR, EIS (image stabilizer), Mirror, Defog.
- Built-in lens distortion correction (LDC)
- White balance with 6 modes
- Automatic and manual gain control
- Supports 4-zone video sensor, 4 regions of interest (ROI) and 4-zone privacy mask
- Perimeter protection: line crossing detection, intrusion detection, fast motion detection (all three functions allow classification of people and vehicles), loitering detection, people gathering and parking detection.
- Smart detection of abandoned objects, missing objects, etc.
- SMD 3.0: fewer false alarms, greater detection distance
- Heat map support
- Face detection with 6 attribute and 8 facial expression extraction.
- People counting: multi-line people counting, generation, people counting in an area and queue management.
- Video metadata
- Built-in microphone
- 1 audio input / 1 RCA audio output
- 2 alarm inputs / 1 alarm output
- HDMI 1.4a output with a maximum resolution of 2560x1440@25/30fps, maximum frame rate for 1080P and 720P is 50/60 fps
- Self-adaptive HDMI, which automatically adjusts the output resolution according to the maximum resolution supported by the camera and display.
- MicroSD card slot for up to 512 GB (not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP, P2P
- ONVIF support (Profile S/G/T), CGI, SDK and API
- Up to 20 users
- Remote viewing via browsers
- Smart PSS Lite, DSS, DMSS, Smart PSS Lite management software
- Compatible with IOS and Android mobile devices
- Power: 12V DC / PoE (802.3af) / ePoE
- Maximum power consumption: 8.3 W (12 V), 8.8 W (PoE)
- Storage temperature: -40°C ~ +60°C
- Relative storage humidity: ≤95% (non-condensing)
- Operating temperature: -30°C ~ +60°C (-30°C ~ +60°C)
- Relative operating humidity: ≤95% (non-condensing)
- IP67 protection rating
- IK10 vandal protection
- Metal casing
- Dimensions: Ø159.1 x 118.1 mm
- Net weight: 920 g
- Gross weight: 1.22 kg
- 3 AXES: 0°~355°(PAN), 0°~65°(TILT), 0°~355°(ROTATION)
