Description
- 16 IP channels
- Video compression: Smart H.265+, H.265, Smart H.264+, H.264, MJPEG
- Simultaneous / heterogeneous (configurable) HDMI (4K) and VGA video outputs
- Main display output division: 1, 4, 8, 9, 9, 16.
- Secondary display output division: 1, 4, 8, 8, 9, 16
- 1 RCA audio input / 1 RCA audio output
- Audio compression: PCM, G.711a, G.711u, G726
- Recording resolution: 16MP, 12MP, 8MP, 6MP, 5MP, 4MP, 1080P, 1.3MP, 720P, D1, CIF
- Bandwidth with AI disabled: 256 Mbps input, 256 Mbps recording, 256 Mbps output
- Bandwidth with AI enabled: 180 Mbps input, 180 Mbps recording, 180 Mbps output
- Decoding capability with AI disabled: 2 channels at 16MP (30 fps), 2 channels at 12MP (30 fps), 4 channels at 8MP (30 fps), 4 channels at 6MP (30 fps), 6 channels at 5MP (30 fps), 8 channels at 4MP (30 fps), 16 channels 1080P (30 fps).
- AI-enabled decoding capability: 1 channel at 16MP (30 fps), 2 channels at 12MP (30 fps), 3 channels at 8MP (30 fps), 3 channels at 6MP (30 fps), 4 channels at 5MP (30 fps), 6 channels at 4MP (30 fps), 12 channels at 1080P (30 fps), 16 channels at 720P (30 fps).
- Recording modes: general, motion detection, intelligence, alarm
- Motion detection alarm, privacy mask, video loss, scene change, PIR alarm, external IP camera alarm
- AI on recorder:
- Perimeter protection up to 2 channels with 10 IVS rules per channel.
- Face detection with up to 1 attribute channel and up to 12 frames per second per channel.
- Face recognition with attributes up to 1 channel, up to 12 frames per second and up to 10 databases with 20,000 images.
- SMD Plus up to 4 channels with filtering between people and vehicles
- AI support for compatible IP cameras
- Supports up to 16 IP cameras with perimeter protection.
- Supports up to 16 IP cameras with face detection
- Supports up to 16 IP cameras with face recognition
- Supports 16 IP cameras with SMD Plus
- Playback up to 16 channels
- 4 alarm inputs / 2 alarm outputs
- Internal capacity for 2 SATA hard drives up to 16 TB (sold separately)
- 16 PoE+ ports (802.3af/at) 10/100Mbps
- 130W total PoE power
- Gigabit Ethernet RJ45 network port (10/100/1000Mbps)
- Network protocols: HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, UDP, SMTP, NTP, DHCP, DNS, IP filtering, PPPoE, DDNS, FTP, Alarm Server, IP search (supports Dahua IP cameras, DVRs, NVS, etc.), P2P, Auto-registration
- ONVIF 22.06 (Profile T/S/G), CGI and SDK support
- Compatible with web browsers, Android and iOS devices
- Access to local network server and Internet
- Possibility to limit user access to cameras in local and/or remote mode
- Can be controlled remotely via a Joystick keyboard connected via TCP/IP
- Send emails with attached photo in case of alarm
- Send to FTP scheduled or on alarm
- Possibility to send an alarm, and to be connected to a video surveillance reception software.
- Possibility of fixed or dynamic IP via Dyndns, NoIP, DDNS Evolution, etc. service
- Communication ports: 2 USB 2.0 ports
- Power supply: 100V ~ 240V AC, 47/63 Hz
- Power consumption: ≤10W (without disks)
- Storage temperature: -20°C ~ +60°C
- Operating temperature from -10°C ~ +55°C
- Relative humidity 10%~93%.
- Dimensions: 375 (L) x 53 (H) x 329.3 mm
- Net weight: 2.6 kg
- Gross weight: 3.8 kg
- Rack or desktop installation
