Description
- 8 IP channels
- Video compression: Smart H.265+, H.265, Smart H.264+, H.264, MJPEG
- Simultaneous/heterogeneous (configurable) HDMI (4K) and VGA video outputs
- Main screen output division: 1, 4, 8, 9
- Secondary screen output division: 1, 4, 8, 9
- 1 RCA audio input / 1 RCA audio output
- Audio compression: PCM, G.711a, G.711u, G726
- Recording resolution: 16MP, 12MP, 8MP, 6MP, 5MP, 4MP, 1080P, 1.3MP, 720P, D1, CIF
- Bandwidth: 80 Mbps input, 80 Mbps recording, 80 Mbps output
- Decoding capacity with AI disabled: 2 channels at 16MP (30 fps), 2 channels at 12MP (30 fps), 4 channels at 8MP (30 fps), 4 channels at 6MP (30 fps), 6 channels at 5MP (30 fps), 8 channels at 4MP (30 fps)
- Decoding capacity with AI enabled: 1 channel at 16MP (30 fps), 2 channels at 12MP (30 fps), 3 channels at 8MP (30 fps), 3 channels at 6MP (30 fps), 4 channels at 5MP (30 fps), 6 channels at 4MP (30 fps), 8 channels at 1080P (30 fps)
- General, motion detection, intelligence, alarm recording modes
- Motion detection alarm, privacy mask, video loss, scene change, PIR alarm, external IP camera alarm
- AI on the recorder:
- Perimeter protection up to 2 channels with 10 IVS rules per channel.
- Face detection with up to 1 attribute channel and up to 12 frames per second per channel.
- Face recognition with attributes up to 1 channel, up to 12 frames per second and up to 10 databases with 20,000 images.
- SMD Plus up to 4 channels with filtering between people and vehicles
- AI support by compatible IP cameras
- Supports up to 8 IP cameras with perimeter protection.
- Supports up to 8 IP cameras with face detection
- Supports up to 8 IP cameras with face recognition
- Supports up to 8 IP cameras with SMD Plus
- Playback up to 8 channels
- Internal capacity for 1 SATA hard drive up to 16TB (sold separately)
- RJ45 Fast Ethernet network port (10/100 Mbps)
- Network protocols: HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, UDP, SMTP, NTP, DHCP, DNS, IP filtering, PPPoE, DDNS, FTP, alarm server, IP search (supports Dahua IP cameras, DVR, NVS, etc.), P2P, auto registration.
- ONVIF 22.06 (Profile T/S/G), CGI and SDK support
- Compatible with web browsers, Android and iOS devices
- Local network and Internet server access
- Ability to limit user access to cameras in local and/or remote mode
- Can be remotely controlled via a Joystick keyboard connected via TCP/IP
- Email sending with attached photo in case of alarm
- Sending to a programmed FTP or alarm
- Ability to send an alarm, and be connected to a video surveillance receiving software
- Possibility of fixed or dynamic IP via Dyndns, NoIP, DDNS Evolution, etc. service
- Communication ports: 2 USB 2.0 ports
- Power supply: 12V DC, 2 A
- Power consumption: ≤7.8W (excluding disks)
- Storage temperature: -20°C ~ +60°C
- Operating temperature: -10°C ~ +55°C
- Relative humidity 10%~93%.
- Dimensions: 260 (W) x 47.6 (H) x 232.7 mm
- Net weight: 840 g
- Gross weight: 1.43 kg
- Rack or desktop installation
