Description
- 4 PoE IP RJ45 inputs up to 2MP
- Individual PoE power of 25.4W (for a total power of 36W)
- Video compression: Smart H.265, Smart H.264
- HDMI video output
- VGA and AV outputs with aviation port
- Display resolution: 800x600, 1280x1024
- Output split: 1, 4
- 4 audio inputs via PoE
- 1 audio output with aviation port, 1 conversational audio output
- Audio compression: PCM, G.711a, G.711u
- Recording resolution: 1080P (1920x1080), 720P (1280x720), D1 (704x576), (CIF 352x288)
- Sub-stream up to D1
- OSD display with channel information, video duration, GPS position, license plate information
- Image quality adjustable in six levels
- Recording modes: automatic, manual, motion detection, schedule, alarm
- Playback up to 4 channels
- 8 alarm inputs / 1 output
- Supports 1/2 2.5" hard drive up to 2 TB (sold separately) and 1 SD card up to 256 GB (sold separately)
- WEB, AV, VGA and HDMI user interface
- DSM: detection of driver drowsiness, driver distraction, calls while driving, driver absence, use of infrared-blocking sunglasses, smoking while driving, and lens tampering.
- Face detection: face capture and comparison
- License plate recognition: license plate capture and blacklist license plate alarm
- 3 RS-232 ports
- 2 RS-485 ports
- 2 USB 2.0 ports, 1 USB 3.0 port
- Pulse counter
- Integrated GPS, WiFi (2.4GHz) and 3G/4G module, the device can register on a public network to connect to the VMS, and can send all information (video/audio/alarm/gps) via wireless network.
- GPS/GLONASS positioning
- The integrated GPS module can receive location information and upload it to the VMS.
- 1 CAN port
- RJ45 M12 Fast Ethernet (10/100M) RJ45 M12 network port
- Compatible with Chrome, IE9+, Firefox browsers
- Compatible with Android and iOS devices
- Power supply: 6V ~ 36V DC with integrated UPS (allows system protection in case of normal power failure and in case of low vehicle battery voltage)
- Power consumption: 10.2W (without peripherals)
- Operating temperature: -30°C ~ +70°C
- Relative humidity 10%~90%.
- Dimensions: 190 (L) x 60 (H) x 190 mm
- Weight: 2.9 kg
- Certifications: CE, FCC, EN50155, ISO7637-2, ISO16750, BIS
