Description
- 1/1.8" 8-megapixel CMOS sensor
- Compression formats: Smart H.265+, Smart H.264+, H.265, AI H.264, H.264, H.264, MJPEG
- Digital resolution: 8MP (3840x2160), 6MP (3072x2048), 5MP (3072x1728, 2592x1944), 4MP (2688x1520), 3MP (2048x1536, 2304x1296), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
- Default frames per second:
- Stream 1: 8MP (1~25 fps)
- Stream 2: 1080P (1~25 fps)
- Stream 3: 1080P (1~25 fps)
- Stream 4: 1080P (1~25 fps)
- Stream 5: D1 (1~25 fps)
- High frame rate frames per second:
- Stream 1: 8MP (1~50 fps)
- Stream 2: 1080P (1~25 fps)
- Day/night mode with removable mechanical filter (ICR)
- Smart IR: 4 leds, 60 meters
- 0.0006 lux F1.2 (color), 0.0003 lux F1.2 (B/W), 0 lux IR On
- Motorized optics 2.7 ~ 12 mm
- Angle of view: 105°~48°(H), 55°~27°(V), 124°~55°(D)
- Imaging modes: BLC, HLC, WDR 140dB, SSA, 3D-NR, EIS (image stabilizer), Mirror, Defogging.
- Integrated Lens Distortion Correction (LDC)
- White balance with 6 modes
- Automatic gain control
- 4-zone video sensor, 4 regions of interest (ROI) and 8-zone privacy masking
- Perimeter protection: cross-line detection, intrusion detection, fast motion detection (all three functions allow classification of people and vehicles), loitering detection, crowd gathering detection and parking detection.
- Smart detection of abandoned objects, missing objects and disappearing objects
- Thermal mapping support
- Face detection with extraction of 6 attributes and 8 facial expressions
- Face recognition in general mode and people counting mode, with a database of up to 200,000 faces
- People counting: multi-line people counting, generation, area people counting and queue management
- Video metadata
- ANPR, tracking, priority, snapshot
- Parking management
- 1 audio input / 1 RCA output
- 3 alarm inputs / 2 outputs
- 1 BNC video output
- 1 RS485 port
- MicroSD card slot up to 1 TB (not included)
- Network interface: RJ45 (10/100/1000 Base-T)
- Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP, P2P, Auto logging
- ONVIF support (Profile S/G/T), CGI, SDK and API
- Up to 20 users
- Remote viewing via browsers
- Smart PSS Lite, DSS, DMSS, Smart PSS Lite management software
- Compatible with IOS and Android mobile devices
- Power supply: 12V DC / 24V AC / PoE+ (802.3at) / ePoE
- Maximum power consumption: 18.2 W (12 V), 24.2 W (24 V), 24.3 W (PoE)
- Power output: 12V DC, 165 mA, peak 700 mA
- Storage temperature: -40°C ~ +65°C
- Relative storage humidity: 10% ~ 95%
- Operating temperature: -40°C ~ +65°C
- Relative operating humidity: ≤95%.
- IP67 protection rating
- IK10 vandal protection
- Metal and plastic casing
- Dimensions: 134.2 (L) x 135.1 (H) x 345.6 mm
- Net weight: 1.65 kg
- Gross weight: 2.73 kg
- 3 AXES: 0°~360°(PAN), 0°~90°(TILT), 0°~360°(ROTATION)
