Description
- CMOS 1/2.8" Sony® STARVIS™ 2 megapixels
- Digital resolution: 1080P (1920x1080), 720P (1280x720), D1 (704x576; 704x480)
- Frames per second: 25/30 fps @1080P, 25/30/50/60 fps @720P
- 4-in-1 video output: HDCVI/HDTVI/AHD/CVBS (CVBS is only for debugging)
- 0.005 lux F1.6 (color), 0.0005 lux F1.6 (B/W), 0 lux IR On
- Smart IR: 4 IR leds, up to 150 meters
- Removable mechanical filter
- 32X optical zoom: 4.5 ~ 144 mm
- Viewing angle: 59.6°~2.8°(H), 34.1°~1.6°(V), 67.9°~3.3°(D)
- Auto, semi-auto, and manual focus
- Automatic and manual iris control
- 16X digital zoom
- Image modes: BLC, HLC, WDR 120dB, 2D/3D-NR, Digital Defog
- White balance with 8 modes
- Automatic and manual gain control
- Privacy masks
- Horizontal positioner: 0° ~ 360° continuous
- Vertical positioner: -15° ~ +90°, 180° auto flip, manual speed: 0.1° ~ +90°, 180° auto flip.
- Manual speed: 0.1°~300°/sec (H), 0.1°~200°/sec (V)
- Preset speed: 300°/sec (H), 200°/sec (V)
- 300 presets
- DH-SD and Pelco-D/P protocols (auto recognition)
- 8 tours of 32 presets each, 5 patterns, 5 scans
- RS485 port (1200 ~ 9600 bps)
- 1 audio input
- 2 alarm inputs / 1 alarm output
- Power supply: 24V DC, 2.5A (±25%)
- Power consumption: 10W (21W with active PTZ and IR illumination)
- Operating temperature: -40°C ~ +70°C
- Relative humidity: ≤95%
- IP66 protection rating
- 6KV lightning protection
- Dimensions: Ø185.7 x 310 mm
- Net weight: 3.9 kg
- Gross weight: 7.2 kg
- Wall bracket and power supply included
