Description
- 4-megapixel 1/2.9" CMOS sensor
- Compression formats: Smart H.265+, Smart H.264+, H.265, H.264, MJPEG
- Digital Resolution: 4MP (2688x1520), 4MP (2560x1440), 3MP (2304x1296), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
- Stream 1: 4MP (2688x1520, 1~20 fps), 4MP (2560x1440, 1~25/30 fps)
- Stream 2: D1 (1~25/30 fps)
- Day/night mode with removable mechanical filter
- Smart IR: 3 IR LEDs, 30 meters
- 0.008 lux F1.6 (color), 0.0008 lux F1.6 (B/W), 0 lux IR on
- 2.8mm fixed lens
- Viewing angle: 102°(H), 54°(V), 121°(D)
- Imaging modes: BLC, HLC, WDR 120dB, 3D-NR, Mirror
- White balance with 6 modes
- Automatic and manual gain control
- Supports 4-zone video sensor, 4 regions of interest (ROI) and 4-zone privacy mask
- Perimeter protection with cross-line detection and intrusion detection (both modes support human/vehicle classification)
- SMD Plus
- Built-in microphone
- MicroSD card slot up to 256GB (not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, NTP, Multicast, ICMP, IGMP
- Supports ONVIF (Profile S/G), CGI, P2P, SDK and API
- Up to 6 users
- Remote viewing via IE, Chrome, Firefox browsers
- DSS, DMSS management software
- Compatible with IOS and Android mobile devices
- Power: 12V DC / PoE (802.3af)
- Maximum power consumption: 5W (12V) / 6W (PoE)
- Operating temperature: -40°C ~ +60°C
- Relative humidity: <95%
- IP67 protection rating
- IK10 vandal resistant
- Metal casing
- Black color
- Dimensions: Ø109.9 x 81 (H) mm
- Weight: 340 g
- 3AXIS: 0°~355°(PAN), 0°~65°(TILT), 0°~355°(Rotation)
