Description
- Linux operating system
- 8 IP channels
- Video compression: Smart H.265+, Smart H.264+, H.265 and H.264
- Simultaneous HDMI and VGA video outputs (1080P)
- Output division: 1, 4, 8, 9
- 1 RCA audio input / 1 RCA audio output
- Audio compression: PCM, G.711A, G.711U, G726
- Recording resolution: 8MP, 5MP, 4MP, 4MP, 3MP, 1080P, 720P, D1, CIF
- Bandwidth: 80 Mbps input, 80 Mbps for recording, 60 Mbps output
- Decoding capability: 1 channel at 8MP (30 fps) / 1 channel at 5MP (30 fps) / 2 channels at 4MP (30 fps) / 2 channels at 3MP (30 fps) / 4 channels 1080P (30 fps) / 8 channels 720P (30 fps)
- Manual, alarm, video sensor and scheduled recording modes
- Video sensor alarm, privacy mask, video loss, PIR alarm, IP camera alarm
- Playback up to 8 channels
- Internal capacity for 1 SATA hard drive up to 8 TB (sold separately)
- 8 PoE 10/100Mbps ports of 25.5W with a total power of 72W
- RJ45 Fast Ethernet network port (10/100Mbps)
- Network protocols: HTTP, HTTPS, TCP/IP, IPv4, IPv6, RTSP, UDP, NTP, DHCP, DNS, P2P
- ONVIF (T/S/G), CGI, SDK support
- Support for Chrome, IE, Firefox web browsers
- Compatible with Android and iOS devices
- Local and internet network access server
- Ability to limit user access to cameras in local and/or remote mode
- Can be remotely controlled via a Joystick keyboard connected via TCP/IP
- Email sending with attached photo in case of alarm
- Sending to FTP scheduled or by alarm
- Possibility to send an alarm, and to be connected to a video surveillance reception software
- Possibility of fixed or dynamic IP via Dyndns, NoIP, DDNS Evolution, etc. service
- Communication ports: 2 USB 2.0 ports
- Power supply: 48V / 53V DC, 2 A / 1.8 A
- Consumption: ≤10W (excluding drives and PoE traffic)
- Storage temperature: 0°C ~ +40°C
- Storage relative humidity of 30%~85% (non-condensing)
- Operating temperature: -10°C ~ +45°C
- 10%~93% operating relative humidity (non-condensing)
- Dimensions: 260 (W) x 47.6 (H) x 225 mm
- Net weight: 840 g
- Gross weight: 1.98 kg
- Tabletop installation
