Description
- 8 Megapixel 1/2.7" CMOS Sensor
- AI-H.265, AI-H.264, Smart H.265+, Smart H.264+, H.265, H.264, MJPEG video formats
- Digital resolution: 8MP (3840x2160), 6MP (3072x2048), 5MP (3072x1728, 2592x1944), 4MP (2688x1520), 3.6MP (2560x1440), 3MP (2304x1296, 2048x1536), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576, 704x480), VGA (640x480), CIF (352x288, 352x240)
- Stream 1: 8MP (1~25/30 fps)
- Stream 2: D1 (1~25/30 fps)
- Stream 3: 1080P (1~25/30 fps)
- Day/night mode with removable mechanical filter (ICR)
- Smart Dual Light: 2 IR LEDs + 2 warm light LEDs, 30 meters
- 0.004 lux F1.0 (color), 0.0004 lux F1.0 (B/W), 0 lux with light on
- 2.8mm fixed optic
- Viewing angle: 106°(H), 55°(V), 125°(D)
- Imaging modes: BLC, HLC, WDR 120dB, SSA, 3D-NR, Mirror, Defog
- Built-in Lens Distortion Correction (LDC)
- White balance with 6 modes
- Automatic and manual gain control
- Supports 4-zone video sensor, 4 Regions of Interest (ROI) and 4-zone privacy mask
- Perimeter protection with cross-line detection and intrusion detection (both modes support human/vehicle classification)
- SMD 4.0: fewer false alarms, greater detection distance
- Built-in dual microphone and speaker
- 1 audio input / 1 audio output
- 1 alarm input / 1 alarm output
- MicroSD card slot up to 512GB (not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP, P2P
- ONVIF support (Profile S/T/G), CGI, SDK, API
- Up to 20 users
- Remote viewing via IE, Chrome and Firefox browsers
- SmartPSS Lite, DSS, DMSS management software
- Compatible with IOS and Android mobile devices
- Power: 12V DC / PoE (802.3af)
- Maximum power consumption: 7.7 W (12V) / 9.4 W (PoE)
- Storage temperature: -40°C ~ +60°C
- Operating temperature: -40°C ~ +60°C
- Relative humidity: ≤95% (non-condensing)
- IP67 protection rating
- Metal and plastic housing
- Color: white
- Dimensions: 94.4 (W) x 84.7 (H) x 288.4 mm
- Net weight: 1 kg
- Gross weight: 1.23 kg
- 3AXIS: 0°~360°(PAN), 0°~90°(TILT), 0°~360°(Rotation)
