Description
- 4 megapixel 1/2.9" CMOS sensor
- Smart H.265+, Smart H.264+, H.265, H.264, MJPEG video formats
- Digital resolution: 4MP (2688x1520), 3.6MP (2560x1440), 3MP (2304x1296), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576, 704x480), VGA (640x480), CIF (352x288, 352x240)
- Stream 1: 4MP (1~20 fps), 3.6MP (1~25/30 fps)
- Stream 2: D1 (1~25/30 fps)
- Day/night mode with removable mechanical filter (ICR)
- Smart Dual Light: 4 LEDs with dual IR core and white light, 60 meters
- 0.006 lux F1.5 (color), 0.0006 lux F1.5 (B/W), 0 lux with illumination activated
- Motorized optics 2.7 ~ 13.5 mm
- Viewing angle: 97°~28°(H), 52°~16°(V), 117°~32°(D)
- Image modes: BLC, HLC, WDR 120dB, 3D-NR, Mirror
- White balance with 6 modes
- Automatic and manual gain control
- Supports 4-zone video sensor, 4 regions of interest (ROI) and 4-zone privacy masking
- Perimeter protection with cross-line detection and intrusion detection (both modes support human/vehicle classification)
- SMD Plus
- Built-in microphone
- 1 RCA audio input / 1 RCA audio output
- 1 alarm input / 1 alarm output
- MicroSD card slot up to 256GB (not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, NTP, Multicast, ICMP, IGMP, P2P
- ONVIF (Profile S/T/G), CGI support
- Up to 6 users
- Remote viewing via IE, Chrome and Firefox browsers
- Smart PSS Lite, DSS, DMSS, DoLynk management software
- Compatible with iOS and Android mobile devices
- Power supply: 12V DC / PoE (802.3af)
- Maximum power consumption: 10.2 W (12 V) / 12.7 W (PoE)
- Storage temperature: -30°C ~ +60°C
- Operating temperature: -30°C ~ +60°C
- Relative humidity: ≤95% (non-condensing)
- IP67 protection rating
- Metal housing
- Dimensions: 90.7 (L) x 90.7 (H) x 238.5 mm
- Net weight: 760 g
- Gross weight: 950 g
- 3AXIS: 0°~360°(PAN), 0°~90°(TILT), 0°~360°(Rotation)
