Description
- 1/2.8" 2-megapixel CMOS sensor
- Smart H.265+, Smart H.264+, H.265, H.264, and MJPEG video formats
- Digital resolution: 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576, 704x480), VGA (640x480), CIF (352x288, 352x240)
- Stream 1: 1080P (1~25/30 fps)
- Stream 2: D1 (1~25/30 fps)
- Day/night mode with removable mechanical filter (ICR)
- Smart Dual Light: 2 dual-core IR and white light LEDs, 40 meters
- 0.002 lux F1.5 (color), 0.0002 lux F1.5 (B/W), 0 lux with illumination on
- 2.7 ~ 13.5 mm motorized lens
- Viewing angle: 109°~30°(H), 56°~17°(V), 131°~35°(D)
- Image modes: BLC, HLC, WDR 120dB, 3D-NR, Mirror
- White balance with 6 modes
- Automatic and manual gain control
- Supports 4-zone video sensor, 4 regions of interest (ROI), and 4-zone privacy masking
- Perimeter protection with cross-line detection and intrusion detection (both modes support human/vehicle classification)
- SMD Plus
- Built-in microphone
- MicroSD card slot up to 256GB (not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, NTP, Multicast, ICMP, IGMP, P2P
- ONVIF (Profile S/T/G), CGI support
- Up to 6 users
- Remote viewing via IE, Chrome, and Firefox browsers
- Smart PSS Lite, DSS, DMSS, DoLynk care management software
- Compatible with IOS and Android mobile devices
- Power supply: 12V DC / PoE (802.3af)
- Power consumption: 7.8 W (12 V) / 9.3 W (PoE)
- Storage temperature: -30°C ~ +60°C
- Operating temperature: -30°C ~ +60°C
- Relative humidity: ≤95% (non-condensing)
- IP67 protection rating
- Metal casing
- Dimensions: Ø122 x 108.3 (H) mm
- Net weight: 690 g
- Gross weight: 860 g
- 3AXIS: 0°~360°(PAN), 0°~78°(TILT), 0°~360°(Rotation)
