Description
- 2 megapixel 1/2.8" CMOS sensor
- Compression formats: Smart H.265+, Smart H.264+, H.265, AI H.264, H.264, H.264, MJPEG
- Digital resolution: 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576, 704x480), CIF (352x288, 352x240)
- Stream 1: 1080P (1~25/30 fps)
- Stream 2: D1 (1~25/30 fps)
- Day/night mode with removable mechanical filter
- Smart Light: 4 multi-core LEDs (IR LED + warm light LED) up to 30 meters
- 0.002 lux F1.6 (colour), 0.0002 lux F1.6 (B/W), 0 lux IR On
- 2.8 mm fixed optic
- Viewing angle: 105°(H), 56°(V), 126°(D)
- Imaging modes: BLC, HLC, WDR 120dB, 3D-NR, Mirror
- White balance with 6 modes
- Automatic and manual gain control
- Supports 4-zone video sensor, 4 regions of interest (ROI) and 4-zone privacy mask
- Perimeter protection with cross-line detection and intrusion detection (both modes support human/vehicle classification)
- SMD Plus
- Built-in microphone
- 1 RCA audio input / 1 RCA audio output
- 1 alarm input / 1 alarm output
- MicroSD card slot up to 256 GB (not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, NTP, Multicast, ICMP, IGMP, P2P
- Supports ONVIF (Profile S/T/G), CGI, SDK and API
- Up to 6 users
- Remote viewing via IE, Chrome and Firefox browsers
- SmartPSS Lite, DSS, DMSS, Dolynk Care management software
- Compatible with IOS and Android mobile devices
- Power supply: 12V DC / PoE (802.3af)
- Power consumption: 1.9W ~ 6.4W (12V) / 2.3W ~ 7.7W (PoE)
- Storage temperature: -40°C ~ +60°C (-40°C ~ +60°C)
- Operating temperature: -40°C ~ +60°C
- Relative humidity: ≤95%
- IP67 protection rating
- IK10 vandal-proof
- Metal casing
- Dimensions: Ø108.9 (L) x 55 (H) mm
- Net weight: 410 g
- Gross weight: 555 g
- 3AXIS: -30°~30°(PAN), 0°~80°(TILT), 0°~360°(Rotation)
