Description
- 4 megapixel 1/2.9" CMOS sensor
- Compression formats: Smart H.265+, Smart H.264+, H.265, AI H.264, H.264, MJPEG
- Digital resolution: 4MP (2688x1520), 3.6MP (2560x1440), 3MP (2304x1296), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576, 704x480), VGA (640x480), CIF (352x288, 352x240)
- Stream 1: 4MP (1~20 fps), 3.6MP (1~25/30 fps)
- Stream 2: D1 (1~25/30 fps)
- Day/night mode with removable mechanical filter (ICR)
- Smart Dual Light: 3 IR LEDs + 4 warm light LEDs, up to 30 meters
- 0.006 lux F1.6 (color), 0.0006 lux F1.6 (B/W), 0 lux IR On
- 3.6mm fixed lens
- Viewing angle: 83°(H), 43°(V), 100°(D)
- Imaging modes: BLC, HLC, WDR 120dB, 3D-NR, Mirror
- White balance with 6 modes
- Automatic and manual gain control
- 4-zone video sensor, 4 regions of interest (ROI) and 4-zone privacy masking
- Perimeter protection with cross-line detection and intrusion detection (both modes support human/vehicle classification)
- SMD Plus
- Built-in microphone
- MicroSD card slot up to 256GB (not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, NTP, Multicast, ICMP, IGMP, P2P
- ONVIF (Profile S/T/G), CGI, SDK and API support
- Up to 6 users
- Remote viewing via IE, Chrome and Firefox browsers
- Smart PSS Lite, DSS, DMSS, DoLynk management software
- Compatible with IOS and Android mobile devices
- Power supply: 12V DC / PoE (802.3af)
- Power consumption: 6.6 W (12V) / 7.9 W (PoE)
- Storage temperature: -40°C ~ +60°C
- Operating temperature: -40°C ~ +60°C
- Relative humidity: ≤95%
- IP67 protection rating
- IK10 vandal protection
- Metal casing
- Dimensions: Ø109.9 (L) x 81 (H) mm
- Net weight: 350 g
- Gross weight: 500 g
- 3AXIS: 0°~355°(PAN), 0°~65°(TILT), 0°~355°(Rotation)
