Description
- 8 IP channels
- Video compression: Smart H.265+, H.265, Smart H.264+, H.264, MJPEG
- Heterogeneous video outputs HDMI (4K) and VGA (1080P)
- Main screen output division: 1, 4, 8, 9
- Secondary screen output division: 1, 4, 8, 9
- 1 RCA audio input / 1 output
- Audio compression: PCM, G.711a, G.711u, G726
- Recording resolution: 32MP, 24MP, 16MP, 12MP, 8MP, 5MP, 4MP, 1080P, 720P, D1, CIF, QCIF
- Bandwidth with AI disabled: 512 Mbps input, 512 Mbps storage and 512 Mbps output
- Bandwidth with AI enabled: 200 Mbps input, 200 Mbps storage and 200 Mbps output
- Decoding capability with AI disabled: 8 channels 8MP (30 fps), 5 channels 12MP (30 fps), 4 channels 16MP (30 fps), 2 channels 24MP (25 fps), 2 channels 32MP (25 fps)
- AI-enabled decoding capability: 8 channels 6MP (30 fps), 6 channels 8MP (30 fps), 4 channels 12MP (30 fps), 2 channels 16MP (30 fps), 1 channel 24MP (25 fps), 1 channel 32MP (25 fps)
- General, motion detection, intelligence, alarm, and POS recording modes
- Video sensor alarm, local alarm, alarm box, external camera alarm, network alarm, scene change, PIR alarm, thermal alarm
- NVR Artificial Intelligence:
- Face detection: 8 channels, 12 face images per channel
- Face recognition: 8 channels
- Perimeter protection: 8 channels, 10 IVS rules per channel
- SMD Plus: 8 channels
- Metadata: 8 channels with 23 attribute extractions
- ANPR: all channels (32 targets), with a capacity of 20,000 license plates.
- Camera Artificial Intelligence:
- Face detection: 8 channels
- Face recognition: 8 channels
- Metadata: 8 channels, classification of people, motor vehicles, and non-motor vehicles
- Perimeter protection: all channels (32 targets)
- SMD Plus: all channels (64 targets)
- Playback up to 8 channels
- 4 alarm inputs / 2 alarm outputs
- Internal capacity for 2 SATA HDDs up to 20TB (sold separately)
- New user interface with simpler user experience
- Support for perimeter protection IP cameras and SMD Plus compatible IP cameras
- RJ45 Fast Ethernet network port (10/100/1000Mbps)
- Network protocols: HTTP, HTTPS, TCP/IP, IPv4, IPv6, UDP, NTP, DHCP, DNS, SMTP, UPnP, IP filtering, FTP, DDNS, SNMP, alarm server, P2P, auto registration, IP search (supports IP cameras, DVR, NVS, etc.), ISCSI
- ONVIF 23.06 (Profile T/S/G), CGI and SDK supported
- Compatible with Chrome, IE, and Firefox browsers
- Compatible with Android and iOS devices
- Access to local network server and internet
- Ability to limit user access to cameras in local and/or remote mode
- Can be remotely controlled using a joystick keyboard connected via TCP/IP
- Email sending with attached photo in case of alarm
- Sending to a scheduled or alarm FTP
- Ability to send an alarm, and be connected to a video surveillance receiving software
- Fixed or dynamic IP capability via Dyndns, NoIP, DDNS Evolution, etc. service
- Communication ports: 1 USB 2.0 port, 1 USB 3.0 port, 1 RS232 port, 1 RS485 port
- 8 PoE ports (10/100Mbps, ports 1 to 8 support ePoE)
- PoE power supply 130W
- Power supply: 100V ~ 240V AC, 47/63Hz
- Power consumption: ≤10W (without disks)
- Storage temperature: -20°C ~ +60°C
- Operating temperature: -10°C ~ +55°C
- Relative humidity 10%~93%.
- Dimensions: 375 (W) x 53 (H) x 327.6 mm
- Net weight: 2.59 kg
- Gross weight: 3.74 kg
- 1U size, rack or desktop installation
