Description
- 4-megapixel 1/3" CMOS sensor
- AI-H.265, AI-H.264, Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG compression formats
- Digital resolution: 4MP (2688x1520), 3.6MP (2560x1440), 3MP (2048x1536, 2304x1296), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576, 704x480), VGA (640x480), CIF (352x288, 352x240)
- Stream 1: 4MP (1~25/30 fps)
- Stream 2: D1 (1~25/30 fps)
- Stream 3: 1080P (1~25/30 fps)
- Day/night mode with removable mechanical filter
- Smart IR: 2 leds, up to 40 meters
- 0.005 lux F1.5 (color), 0.0005 lux F1.5 (B/W), 0 lux IR On
- Motorized lens 2.7 ~ 13.5 mm
- Viewing angle: 104°~29°(H), 56°~16°(V), 125°~34°(D)
- Image modes: BLC, HLC, WDR 120dB, SSA, 3D-NR, Defog, Image Stabilizer, Mirror.
- White balance with 6 modes
- Automatic gain control
- Supports 4-zone video sensor, 4 regions of interest (ROI) and 4-zone privacy mask
- Intelligent Video Detection (IVS): abandoned/lost object detection
- Heatmap
- Perimeter protection: cross-line detection, intrusion detection, rapid motion detection (all three functions with people/vehicle classification), parking detection, loitering detection, people gathering.
- SMD 3.0 standard support: fewer false alarms, longer detection distance
- Face detection with 6 attributes and extraction of 8 expressions
- People counting with 4 rules to count people entering and exiting separately
- 1 audio input / 1 audio output
- 3 alarm inputs / 2 alarm outputs
- RS485 port
- MicroSD card slot up to 256 GB (card not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP
- ONVIF S/G/T, CGI, Milestone, Genetec, P2P support
- Up to 20 users
- Remote viewing with IE, Chrome and Firefox browsers
- Smart PSS, DSS, DMSS management software
- Compatible with iOS and Android smartphones
- Power supply: 12V DC / PoE (802.3af)
- Maximum power consumption: 6.2 W (12 V) / 7.3 W (PoE)
- Operating temperature: -40°C ~ +60°C
- Relative humidity <95% (non-condensing)
- IP68 protection rating
- IK10 vandal protection
- 316L stainless steel housing
- Dimensions: Ø165 x 118.2 (H) mm
- Net weight: 4.5 kg
- Gross weight: 5.3 kg
- 3AXIS: 0°~355° (PAN), 0°~75°(TILT), 0°~355°(Rotation)
- CE, FCC, ATEX, IECEx certified
