Description
- 5 megapixel 1/2.7" CMOS sensor
- Compression formats: Smart H.265+, Smart H.264+, H.265, H.264, MJPEG
- Digital Resolution: 5MP (2960x1668), 4.6MP (2880x1620), 4MP (2688x1520), 3MP (2048x1536, 2304x1296), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576, 704x480), VGA (640x480), CIF (352x288, 352x240)
- Stream 1: 5MP (1~20 fps), 4.6MP (1~25/30 fps)
- Stream 2: D1 (1~25/30 fps)
- Day/night mode with removable mechanical filter
- Smart IR: 1 IR LED, 30 meters
- 0.007 lux F1.6 (color), 0.0007 lux F1.6 (B/W), 0 lux IR on
- 2.8mm fixed optics
- Viewing angle: 111°(H), 58°(V), 132°(D)
- Imaging modes: BLC, HLC, WDR 120dB, 3D-NR, Mirror
- White balance with 6 modes
- Automatic and manual gain control
- Supports 4-zone video sensor, 4 regions of interest (ROI) and 4-zone privacy mask
- Perimeter protection with cross-line detection and intrusion detection (both modes support human/vehicle classification)
- SMD Plus
- Built-in microphone
- MicroSD card slot up to 256GB (not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, Bonjour, P2P
- Support ONVIF (Profile S/G/T), CGI, Milestone, SDK and API
- Up to 20 users
- Remote viewing via IE, Chrome, Firefox browsers
- Smart PSS Lite, DSS, DMSS management software
- Compatible with IOS and Android mobile devices
- Power supply: 12V DC / PoE (802.3af)
- Maximum power consumption: 4.1W (12V) / 5W (PoE)
- Storage temperature: -40°C ~ +60°C
- Operating temperature: -30°C ~ +60°C
- Relative humidity: ≤95%
- IP67 degree of protection
- Metal housing
- Dimensions: Ø121.9 x 99.1 (H) mm
- Net weight: 480 g
- Gross weight: 680 g
- 3AXIS: 0°~360°(PAN), 0°~78°(TILT), 0°~360°(Rotation)
