Description
- 128 IP channels
- Video compression: Smart H.265+, H.265, Smart H.264+, H.264, MJPEG
- 4 HDMI video outputs (HDMI1/2 4K, HDMI3 8K, HDMI4 1080P) and 2 simultaneous/heterogeneous VGA outputs (1080P)
- Primary display output division: 1, 4, 8, 9, 16, 25, 36, 64
- Secondary display output division: 1, 4, 8, 9, 16, 25, 36, 64
- 1 RCA input / 2 RCA audio outputs
- Two-way audio via RCA input / RCA output
- Recording resolution: 32MP, 24MP, 16MP, 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 960P, 720P, D1, CIF
- Bandwidth with AI disabled: 1280 Mbps input, 1280 Mbps recording, 1024 Mbps output
- Bandwidth with AI enabled: 640 Mbps input, 640 Mbps recording, 512 Mbps output
- Decoding capability without AI: 2 channels at 32MP (30 fps), 2 channels at 24MP (30 fps), 4 channels at 16MP (30 fps), 5 channels at 12MP (30 fps), 8 channels at 8MP (30 fps), 12 channels at 5MP (30 fps), 16 channels at 4MP (30 fps), 32 channels at 1080P (30 fps), 128 channels at D1 (30 fps)
- Decoding capability with AI enabled: 1 channel at 32MP (30 fps), 1 channel at 24MP (30 fps), 2 channels at 16MP (30 fps), 2 channels at 12MP (30 fps), 4 channels at 8MP (30 fps), 6 channels at 5MP (30 fps), 8 channels at 4MP (30 fps), 16 channels at 1080P (30 fps), 80 channels at D1 (30 fps)
- General, motion detection, smart, alarm, and POS recording modes
- Video sensor alarm, masking alarm, video loss alarm, scene change alarm, PIR alarm, IP camera
- Up to 16-channel playback
- 32 alarm inputs / 16 alarm outputs
- Internal capacity for 16 SATA III hard drives up to 20 TB (sold separately)
- RAID 0/1/5/6/10, disk pooling, and hot swap support
- 1 eSATA port
- AI port on the recorder
- Perimeter protection: 32 channels in simultaneous mode, 24 channels in heterogeneous mode, 10 IVS rules per channel
- Face detection: 8 channels in simultaneous mode, 5 channels in heterogeneous mode, up to 12 frames per second per channel
- Face recognition: 32 channels in simultaneous mode, 16 channels in heterogeneous mode, up to 12 frames per second and up to 40 databases with 300,000 images.
- SMD Plus: 32 channels with filtering between people and vehicles
- Video metadata: 8 channels with people and vehicle attributes
- AI support from compatible cameras:
- Supports 64 cameras with perimeter protection.
- Supports up to 64 cameras with face detection
- Supports 64 cameras with face recognition
- Supports up to 64 cameras with SMD Plus
- Supports 64 cameras with video metadata
- Supports 64 ANPR cameras (up to 20,000 whitelist/blacklist entries)
- Watermark to preserve video integrity
- 4 RJ45 network ports (10/100/1000/2500Mbps)
- Network protocols: HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, NTP, DHCP, DNS, SMTP, UPnP, DDNS, alarm server, IP search (supports Dahua IP cameras, DVR, NVS, etc.), Multicast, P2P, automatic recording, ISCSI
- Compatible with ONVIF 22.06 (S/G/T), SDK, CGI
- Compatible with Chrome, IE, Safari, Edge, and Firefox browsers and iOS and Android devices
- Access to local network server and internet
- Ability to limit user access to cameras in local and/or remote mode
- Can be remotely controlled via a Joystick keyboard connected by TCP/IP
- Email sending with attached photo in case of alarm
- Scheduled or alarm-triggered sending to FTP
- Ability to send an alarm and connect to a video surveillance reception software.
- Ability to use static or dynamic IP via Dyndns, NoIP, DDNS Evolution, etc. services
- Communication ports: 2 USB 3.0 ports, 2 USB 2.0 ports, 2 RS485 ports, 1 RS232 port
- Power supply: 100V ~ 240V AC, 50/60Hz
- Power consumption: ≤25W (without disks)
- Storage temperature: -20°C ~ +60°C
- Operating temperature: -10°C ~ +55°C
- Relative humidity 10% ~ 93% (non-condensing)
- Dimensions: 485 (W) x 133.2 (H) x 529 mm
- Net weight: 13.3 kg
- Gross weight: 15.42 kg
- Desktop or 3U rack installation
