Description
- 5 technologies: IP, HDCVI, HDTVI, AHD, and analog CVBS cameras with automatic signal recognition
- 4 BNC channels up to 1080N (BNC inputs can be converted to IP)
- Up to 5 IP channels (1 default IP channel + 4 analog channels converted to IP channels)
- Video compression: AI, H.265+, H.265, H.264+, H.264
- HDMI (1080P) and VGA (up to 1080P) video outputs
- Output division with extended IP mode disabled: 1, 4
- Output division with extended IP mode enabled: 1, 4, 6
- Two-way audio: 1 RCA audio input / 1 RCA audio output
- 4 audio inputs via coaxial cable
- Audio compression: G.711a, G.711u, PCM
- Recording resolution:
- CVI: 1080P (25/30 fps), 720P (25/30 fps)
- TVI: 1080P (25/30 fps), 720P (25/30 fps)
- AHD: 1080P (25/30 fps), 720P (25/30 fps)
- Bandwidth: 32 Mbps input, 32 Mbps recording, and 32 Mbps output (with extended IP mode, AI SMD function will be disabled)
- Main stream: 1080N, 720P, 960H, D1, CIF (1~25/30 fps)
- Secondary stream: CIF (1~15 fps)
- General, video detection, and alarm recording modes
- Playback of up to 4 channels
- SMD Plus: 4 channels, person/vehicle classification
- Internal capacity for 1 SATA hard drive up to 16TB (sold separately)
- Multilingual on-screen menu
- Ability to update DAHUA camera firmware from the recorder itself
- Software and hardware monitoring
- Watermark to preserve video integrity
- RJ45 10/100Mbps network port
- Network protocols: HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, P2P
- ONVIF 21.12, CGI support
- Remote access from a web browser and iPhone, iPad, Android devices (EVO App and TTS)
- Email with attached photo in case of alarm
- Upload to FTP scheduled or on alarm
- Ability to send an alarm and connect to an alarm receiving software (C.R.A.) via the free AlarmSpace software
- Fixed or dynamic IP via the Evolution DDNS service
- Communication ports: 2 USB 2.0 ports, 1 RS485 port
- Power supply: 12V DC, 1.5A (<4W, without drives)
- Operating temperature: -10°C ~ +55°C
- Relative humidity 0% ~ 90%
- Dimensions: 260 (W) x 47.6 (H) x 237.9 mm
- Net weight: 860 g
- Gross weight: 1.37 kg
- Desktop installation
- CE, FCC certified
