Description
- High-performance 64-bit multi-core processor
- Linux operating system
- Maximum 320 IP camera inputs
- Maximum 800 Mbps input/recording/transmission bandwidth
- Supports up to 16 hot-swappable SATA hard drives
- Supports RAID 0/1/5/6/10/50/60
- Supports direct video/image storage mode and IPSAN storage mode
- Supports Automatic Network Replenishment (ANR)
- Modular and drawer design
- Redundant power supply
- Communication: 1 eSATA port, 1 RS232 port, 2 USB 3.0 ports, 1 HDMI port (debug), 1 VGA port (debug)
- 2 auto-adaptive 10/100/1000 Mbps RJ45 network ports (electrical gigabit port)
- Power supply 100V ~ 240V AC, 50/60Hz
- Power consumption 60W (without drives, idle), 220W (with all drives)
- Operating temperature 0°C ~ +45°C (32°F ~ +40°F)
- Relative humidity 10% ~ 80% (non-condensing)
- Fans with intelligent speed control
- Dimensions: 484.6 (W) x 133.2 (H) x 473.6 mm
- Net weight: 15.5 kg
- Gross weight: 17.2 kg
- 19-inch rack-mountable
