Description
- 4-megapixel 1/1.8" CMOS sensor
- Compression formats: Smart H.265+, Smart H.264+, H.265, AI H.264, H.264, H.264, MJPEG
- Digital resolution: 4MP (2688x1520), 3MP (2048x1535, 2304x1296), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576, 704x480), VGA (640x480), CIF (352x288, 352x240)
- Stream 1: 4MP (1~50/60 fps)
- Stream 2: 1080P (1~25/30 fps)
- Stream 3: 1080P (1~25/30 fps)
- Stream 4: 1080P (1~25/30 fps)
- Stream 5: D1 (1~25 fps)
- Day/night mode with removable mechanical filter (ICR)
- Smart IR: 4 leds, 60 meters
- 0.0005 lux F1.2 (color), 0.0002 lux F1.2 (B/W), 0 lux IR On
- 2.7 ~ 12 mm motorized optic
- Viewing angle: 107°~48°(H), 55°~27°(V), 130°~56°(D)
- Imaging modes: BLC, HLC, WDR 140dB, SSA, 3D-NR, EIS (image stabilizer), Mirror, Defog
- White balance with 6 modes
- Automatic gain control
- Supports 4-zone video sensor, 4 Regions of Interest (ROI) and 8-zone privacy mask
- Perimeter protection: cross-line detection, intrusion detection, fast motion detection (all three functions classify people and vehicles), loitering detection, crowd gathering, and parking detection.
- Smart detection of abandoned objects, missing objects, and disappearing objects
- Supports thermal mapping
- Face detection with 6 attribute and 8 facial expression extraction
- Face recognition in general mode and people counting mode, with a database of up to 200,000 faces
- People counting: multi-line people counting, generation, people counting in an area, and queue management
- Video metadata
- ANPR, tracking, priority, snapshot
- Parking management
- 1 RCA audio input / 1 output
- 3 alarm inputs / 2 outputs
- 1 BNC video output
- 1 RS485 port
- MicroSD card slot up to 512GB (not included)
- Network interface: RJ45 (10/100/1000 Base-T)
- Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP, P2P
- ONVIF support (Profile S/G/T), CGI, SDK, API
- Up to 20 users
- Remote viewing via browsers
- Smart PSS Lite, DSS, DMSS, Smart PSS Lite management software
- Compatible with IOS and Android mobile devices
- Power: 12V DC / 24V AC / PoE+ (802.3at) / ePoE
- Maximum power consumption: 18.2W (12V), 24.2W (24V), 24.3W (PoE)
- Storage temperature: -40°C ~ +65°C
- Storage relative humidity: 10% ~ 95%
- Operating temperature: -40°C ~ +65°C
- Operating relative humidity: ≤95%.
- IP67 degree of protection
- IK10 vandal protection
- Metal and plastic housing
- Dimensions: 134.2 (W) x 135.1 (H) x 345.6 mm
- Gross weight: 2.37 kg
- Net weight: 1.65 kg
- 3 AXES: 0°~360°(PAN), 0°~90°(TILT), 0°~360°(ROTATION)
