Description
- 16 IP channels
- Video compression: Smart H.265+, Smart H.264+, H.265, H.264 and MJPEG
- Simultaneous HDMI (4K) and VGA (1080P) video outputs
- Output division: 1, 4, 8, 8, 9, 16
- 1 RCA audio input / 1 RCA audio output
- Audio compression: G.711a, G.711u, PCM, G726
- Recording resolution: 12MP, 8MP, 5MP, 4MP, 3MP, 1080P, 720P, D1
- Bandwidth with AI disabled: 144 Mbps input, 144 Mbps for recording, and 72 Mbps output
- Bandwidth with AI enabled: 72 Mbps input, 72 Mbps for recording, and 36 Mbps output
- Decoding capacity with AI disabled:
- 1 channel at 12MP (30 fps)
- 1 channel at 8MP (30 fps)
- 2 channels at 5MP (30 fps)
- 3 channels at 4MP (30 fps)
- 6 channels 1080P (30 fps)
- Decoding capacity with AI enabled:
- 1 channel at 8MP (30 fps)
- 1 channel at 5MP (30 fps)
- 2 channels at 4MP (30 fps)
- 4 channels 1080P (30 fps)
- General, motion detection, intelligence, and alarm recording modes
- Video sensor alarm, external camera alarm, PIR alarm
- Artificial intelligence from smart cameras:
- Perimeter protection: 4 channels
- SMD Plus: 4 channels
- Artificial intelligence on the recorder:
- SMD Plus: 4 channels
- Playback up to 16 channels
- Internal capacity for 1 SATA HDD up to 20TB (sold separately)
- RJ45 Gigabit Ethernet (10/100/1000Mbps) network port
- Network protocols: HTTP, HTTPS, TCP/IP, IPv4, IPv6, UDP, NTP, DHCP, DNS, SMTP, IP filtering, DDNS, IP search (support for IP cameras, DVRs, NVS, etc.), P2P, auto registration
- ONVIF 22.12 (T/S/G), CGI and SDK support
- Compatible with Chrome, IE, Safari, Edge, Firefox browsers
- Compatible with Android and iOS devices
- Local network and Internet server access
- Possibility to limit user access to cameras in local and/or remote mode
- Can be remotely controlled via a joystick keyboard connected via TCP/IP
- Email sending with attached photo in case of alarm
- Send to an FTP server on schedule or alarm
- Possibility of sending an alarm, and being connected to video surveillance reception software
- Possibility of fixed or dynamic IP via Dyndns, NoIP, DDNS Evolution, etc. service
- Communication ports: 2 USB 2.0 ports
- Power supply: 12V DC, 1.5A
- Power consumption: ≤10W (excluding drives)
- Storage temperature: -20°C ~ +60°C
- Operating temperature: -10°C ~ +55°C
- Relative humidity 10%~93% (non-condensing)
- Dimensions: 260 (L) x 47.6 (H) x 232.5 mm
- Net weight: 850 g
- Gross weight: 1.39 kg
- Rack or desktop installation
