Description
- 1/2.8" 4-megapixel CMOS
- Smart H.265+, Smart H.264+, H.265, H.264, and MJPEG video compression
- Resolution: 4MP (2560x1440), 3MP (2304x1296), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576, 704x480), VGA (640x480), CIF (352x288, 352x240)
- Stream 1: 4MP, 3MP, 1080P, 1.3MP, 720P (1~25/30 fps)
- Stream 2: D1, VGA, CIF (1~25/30 fps)
- Stream 3: 720P (1~25/30 fps)
- Day/night mode with removable mechanical filter
- 0.005 lux F1.8 (color), 0.0005 lux F1.8 (B/W), 0 lux IR on
- Smart IR: 3 IR LEDs, up to 20 meters
- 4X optical zoom: 2.8 ~ 12 mm
- Viewing angle: 90.6°~47.3°(H), 49.1°~26.7°(V), 107.4°~5.8°(D)
- Auto, semi-auto, and manual focus
- Fixed iris control
- 16X digital zoom
- Image modes: BLC, HLC, WDR 120dB, 2D/3D-NR, EIS (image stabilizer), digital defogging
- White balance with 8 modes
- Automatic, manual, gain priority gain control
- Video sensor support and regions of interest (ROI)
- Perimeter protection: Line crossing and intrusion detection with person and vehicle classification, fence crossing detection, loitering detection, missing object detection. Loitering, missing/abandoned objects, rapid movement, parking, crowd gathering, etc. detection.
- Support for face detection, snapshot, and face enhancement; support for face cropping: face, thumb photo; capture strategies include real-time capture and quality priority.
- Support for people counting, calculating the number of people in an area, and queue management.
- SMD 3.0
- Horizontal positioner: 0° ~ 355° ~ 355°; Vertical positioner: 5° ~ 355° ~ 355°
- Vertical positioner: 5° ~ 90°.
- Manual speed: 0.1° ~ 70°/sec (H), 0.1° ~ 30°/sec (V)
- Preset speed: 80°/sec (H), 40°/sec (V)
- 300 presets, DH-SD protocol
- 8 tours (up to 32 presets per tour)
- 1 audio input / 1 audio output
- MicroSD card slot up to 512 GB (card not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: FTP, RTMP, IPv6, Bonjour, IPv4, DNS, RTCP, PPPoE, NTP, RTP, 802.1x, HTTPS, SNMP, TCP/IP, DDNS, UPnP, NFS, ICMP, UDP, IGMP, HTTP, SSL, DHCP, SMTP, Qos, RTSP, ARP
- Support ONVIF S/G/T, RTMP, CGI, SDK, ONVIF S/G/T
- Compatible with iOS and Android devices
- Compatible with IE, Chrome, Firefox, Safari browsers
- Up to 20 users
- DSS Pro, DMSS management software
- Power: 12V DC, 2A / PoE (802.3af)
- Power consumption: 4W (basic), 13W (maximum)
- Operating temperature -30°C ~ +60°C
- Relative operating humidity ≤95%.
- IP66 protection rating
- IK08 vandal protection
- 6KV lightning protection
- Dimensions: Ø128 x 65.4 (H) mm
- Net weight: 500 g
- Gross weight: 700 g
