Description
- 128 IP channels
- Video compression: Smart H.265+, H.265, Smart H.264+, H.264, MJPEG
- 4 HDMI video outputs (HDMI1/2 4K, HDMI3 8K, HDMI4 1080P) and 2 simultaneous/heterogeneous VGA outputs (1080P)
- Primary display output division: 1, 4, 8, 8, 9, 16, 25, 36, 64
- Secondary display output division: 1, 4, 8, 9, 16, 25, 36, 64
- 1 RCA input / 2 RCA audio outputs
- Two-way audio via RCA input / RCA output
- Recording resolution: 32MP, 24MP, 16MP, 12MP, 8MP, 5MP, 4MP, 1080P, 720P, D1
- Bandwidth with AI disabled: 1280 Mbps input, 1280 Mbps recording, 1024 Mbps output
- Bandwidth with AI enabled: 640 Mbps input, 640 Mbps recording, 512 Mbps output
- Decoding capability without AI: 2 channels at 32MP (30 fps), 2 channels at 24MP (30 fps), 4 channels at 16MP (30 fps), 5 channels at 12MP (30 fps), 8 channels at 8MP (30 fps), 12 channels at 5MP (30 fps), 16 channels at 4MP (30 fps), 32 channels at 1080P (30 fps), 128 channels at D1 (30 fps)
- Decoding capability with AI enabled: 1 channel at 32MP (30 fps), 1 channel at 24MP (30 fps), 2 channels at 16MP (30 fps), 2 channels at 12MP (30 fps), 4 channels at 8MP (30 fps), 6 channels at 5MP (30 fps), 8 channels at 4MP (30 fps), 16 channels at 1080P (30 fps), 80 channels at D1 (30 fps)
- Manual, calendar, alarm, motion detection, and motion detection recording modes
- Video sensor alarm, masking alarm, video loss alarm, scene change alarm, PIR alarm, IP camera
- Playback up to 16 channels
- 16 alarm inputs / 8 alarm outputs
- Internal capacity for 8 SATA III hard drives up to 16 TB (sold separately)
- RAID 0/1/5/6/10, disk pooling, and hot-swapping support
- 1 eSATA port
- AI port on the recorder
- Perimeter protection: 32 channels in simultaneous mode, 24 channels in heterogeneous mode, 10 IVS rules per channel
- Face detection: 8 channels in simultaneous mode, 5 channels in heterogeneous mode, up to 12 frames per second per channel
- Face recognition: 32 channels in simultaneous mode, 16 channels in heterogeneous mode, up to 12 frames per second and up to 40 databases with 300,000 images.
- SMD Plus: 32 channels with filtering between people and vehicles
- Video metadata: 8 channels with people and vehicle attributes
- AI support from compatible cameras:
- Supports 64 cameras with perimeter protection.
- Supports up to 64 cameras with face detection
- Supports 64 cameras with face recognition
- Supports up to 64 cameras with SMD Plus
- Supports 64 cameras with video metadata
- Supports 64 ANPR cameras (up to 20,000 whitelist/blacklist entries)
- Watermark to preserve video integrity
- 2 RJ45 Fast Ethernet network ports (10/100/1000/2500Mbps)
- Network protocols: HTTP, HTTPS, TCP/IP, IPv4, RTSP, UDP, NTP, DHCP, DNS, SMTP, UPnP, DDNS, alarm server, IP search (supports Dahua IP cameras, DVR, NVS, etc.), Multicast, P2P, automatic recording, ISCSI
- ONVIF (S/G/T), SDK, CGI support
- Remote access from a web browser (Chrome, IE 9, Firefox) and iOS and Android devices
- Server access on the local network and over the Internet
- Ability to limit user access to cameras in local and/or remote mode
- Can be remotely controlled via a Joystick keyboard connected via TCP/IP
- Email sending with attached photo in case of alarm
- Scheduled or alarm-triggered FTP sending
- Ability to send an alarm and connect to a video surveillance reception software
- Ability for fixed or dynamic IP via Dyndns, NoIP, DDNS Evolution, etc. service
- Communication ports: 2 USB 3.0 ports, 2 USB 2.0 ports, 1 RS485 port, 1 RS232 port
- Power supply: 100V ~ 240V AC, 50/60Hz
- Power consumption: ≤18W (without disks)
- Storage temperature: 0°C ~ +40°C
- Operating temperature from -10°C ~ +55°C
- Relative humidity 10% ~ 93% (non-condensing)
- Dimensions: 440 (W) x 94.9 (H) x 458.4 mm
- Net weight: 6.4 kg
- Gross weight: 8.59 kg
- Desktop or 2U rack installation
