Description
- 1/2.8" 2-megapixel CMOS sensor
- Smart H.265, Smart H.264, H.265, H.264, MJPEG compression formats
- Resolution: 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
- Stream 1: 1080P, 1.3MP, 720P (1~25/30 fps)
- Stream 2: D1, VGA, CIF (1~25/30 fps)
- Stream 3: 1080P, 1.3MP, 720P (1~25/30 fps)
- Day/night mode with removable mechanical filter
- Infrared illumination: 4 LEDs, up to 150 meters
- 0.005 lux F1.6 (color) / 0.0005 lux F1.6 (B/W) / 0 lux IR On
- 25X optical zoom: 4.8 ~ 120 mm
- Viewing angle: 58.5°~2.8°(H), 33.2°~1.5°(V), 67.5°~3.2°(D)
- Auto, semi-auto, and manual focus
- Automatic and manual iris control
- 16X digital zoom
- Image modes: BLC, HLC, WDR 120dB, 2D/3D NR, EIS (image stabilizer), digital defog
- White balance with 8 modes
- Automatic and manual gain control
- Supports video sensor, regions of interest (ROI), and 24-zone privacy mask (with up to 8 zones in the same view)
- Perimeter protection: Line crossing detection, intrusion detection, fence crossing detection, loitering detection, abandoned/lost object detection, fast movement, parking detection, people gathering, alarm activation by target type (person or vehicle).
- Supports face detection, face bounding box, optimization, snapshot capture, facial image enhancement and high-quality facial snapshot upload, and extraction of 6 attributes and 8 expressions from facial images.
- Face cropping function, which allows cropping one face at a time and customizing its size to obtain a one-inch photo.
- Supports autotracking
- SMD
- Quick Pick
- Horizontal positioner: 0° ~ 360° continuous
- Vertical positioner: -90° ~ +90°, 180° auto flip
- Manual speed: 0.1° ~ 120°/sec (H), 0.1° ~ 75°/sec (V)
- Preset speed: 160°/sec (H), 110°/sec (V)
- 300 presets
- 5 patterns, 8 tours of 32 presets each, 5 scans
- 1 audio input / 1 audio output
- 2 alarm inputs / 1 alarm output
- MicroSD card slot up to 512GB (card not included)
- Network interface: RJ45 (10/100Base-T)
- Network protocols: FTP, RTMP, IPv6, Bonjour, IPv4, DNS, RTCP, PPPoE, NTP, RTP, 802.1x, HTTPS, SNMP, TCP/IP, DDNS, UPnP, NFS, ICMP, UDP, IGMP, HTTP, SSL, DHCP, SMTP, QoS, RTSP, ARP
- ONVIF (Profile S/G/T), CGI, SDK, P2P support
- Unicast/Multicast streaming method
- Up to 20 users
- Remote viewing via IE, Chrome, Firefox, and Safari browsers
- DMSS, DSS Pro management software
- Compatible with iOS and Android mobile devices
- Power supply: 12V DC, 4A (±10%) / PoE+ (802.3at)
- Power consumption: 16W, 24W with IR and PTZ illumination
- Operating temperature: -40°C ~ +70°C
- Relative humidity: ≤95%.
- IP67 protection rating
- 6KV lightning protection
- Dimensions: 161 (W) x 291.5 (H) 135.4 mm
- Net weight: 3.6 kg
- Gross weight: 6.4 kg
- Power supply included
