Description
- 5 megapixel 1/2.7" CMOS sensor
- Compression formats: Smart H.265+, Smart H.264+, H.265, H.264, MJPEG
- Digital resolution: 5MP (2960x1668), 4.6MP (2880x1620), 4MP (2688x1520), 3MP (2048x1536, 2048x1536), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576, 704x480), VGA (640x480), CIF (352x288, 352x240)
- Stream 1: 5MP (1~20 fps), 4MP (1~25/30 fps)
- Stream 2: D1 (1~25/30 fps)
- Day/night mode with removable mechanical filter
- Smart IR: 2 IR LEDs, 40 meters
- 0.007 lux F1.5 (color), 0.0007 lux F1.5 (B/W), 0 lux IR on
- Motorized optics 2.7 ~ 13.5 mm
- Viewing angle: 113°~31°(H), 58°~18°(V), 138°~36°(D)
- Image modes: BLC, HLC, WDR 120dB, 3D-NR, Mirror
- White balance with 6 modes
- Automatic and manual gain control
- Supports 4-zone video sensor, 4 regions of interest (ROI) and 4-zone privacy masking
- Perimeter protection with cross-line detection and intrusion detection (both modes support human/vehicle classification)
- SMD Plus
- Built-in microphone
- MicroSD card slot up to 256 GB (not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, Bonjour
- ONVIF (profile S/G/T), CGI, P2P, Milestone, SDK, API support
- Up to 20 users
- Remote viewing via IE, Chrome, Firefox browsers
- Smart PSS, DSS, DMSS management software
- Compatible with iOS and Android mobile devices
- Power supply: 12V DC / PoE (802.3af)
- Maximum power consumption: 6.1 W (12 V) / 7.3 W (PoE)
- Storage temperature: -40°C ~ +60°C
- Operating temperature: -30°C ~ +60°C
- Relative humidity: ≤95%.
- IP67 protection rating
- IK10 vandal protection
- Metal housing
- Dimensions: Ø122 x 93.4 (H) mm
- Net weight: 500 g
- Gross weight: 660 g
- 3AXIS: 0°~355°(PAN), 0°~75°(TILT), 0°~355°(Rotation)
