Description
- 32 IP channels
- Video compression: Smart H.265+, H.265, Smart H.264+, H.264
- Simultaneous HDMI (4K) and VGA (1080P) video outputs
- Main display output split with AI disabled: 1, 4, 8, 9, 16, 25, 36
- Sub display output split with AI disabled: 1, 4, 8, 9, 16, 25, 36
- Main display output split with AI enabled: 1, 4, 8, 9, 16
- Sub display output split with AI enabled: 1, 4, 8, 9, 16
- 1 RCA audio input / 1 RCA audio output
- Audio compression: PCM, G.711a, G.711u, G726
- Recording resolution: 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP, 720P, D1, CIF, QCIF
- Bandwidth with AI disabled: 160 Mbps input, 128 Mbps recording, 60 Mbps output
- Bandwidth with AI enabled: 80 Mbps input, 80 Mbps recording, 60 Mbps output
- Decoding capacity with AI disabled:
- 1 channel at 12MP (30 fps)
- 2 channels at 8MP (30 fps)
- 3 channels at 5MP (30 fps)
- 4 channels at 4MP (30 fps)
- 8 channels at 1080P (30 fps)
- Decoding capacity with AI enabled:
- 1 channel at 12MP (30 fps)
- 1 channel at 8MP (30 fps)
- 2 channels at 5MP (30 fps)
- 3 channels at 4MP (30 fps)
- 7 channels at 1080P (30 fps)
- General, motion detection, intelligent, alarm, and alarm recording modes
- Video sensor alarm, privacy mask alarm, video loss, scene change, PIR alarm, external camera
- Artificial intelligence from smart cameras: Perimeter protection (6 channels), face detection (6 channels), face recognition (6 channels), SMD Plus (6 channels)
- Artificial intelligence on the recorder: SMD Plus (4 channels)
- Playback up to 16 channels
- 4 alarm inputs / 2 alarm outputs
- Internal capacity for 2 SATA hard drives up to 20TB (sold separately)
- RJ45 Fast Ethernet network port (10/100/1000Mbps)
- Network protocols: HTTP, HTTPS, TCP/IP, IPv4, UDP, NTP, DHCP, DNS, SMTP, UPnP, IP filter, DDNS, alarm server, IP search (support for IP cameras, DVRs, NVS, etc.), P2P, auto register
- ONVIF 22.12 (T/S/G), CGI, and SDK support
- Compatible with web browsers
- Compatible with Android and iOS devices
- Local network and Internet server access
- Ability to limit user access to cameras in local and/or remote mode
- Can be remotely controlled via a Joystick keyboard connected via TCP/IP
- Email sending with attached photo in case of alarm
- Scheduled or alarm-triggered FTP upload
- Ability to send an alarm and be connected to a video surveillance receiving software
- Ability to use fixed or dynamic IP via Dyndns, NoIP, DDNS Evolution, etc. service
- Communication ports: 2 USB 2.0 ports
- Power supply: 12V DC, 4A
- Power consumption: ≤10W (excluding disks)
- Storage temperature: -20°C ~ +60°C
- Operating temperature: -10°C ~ +55°C
- Relative humidity 10%~93%
- Dimensions: 375 (W) x 53 (H) x 282.9 mm
- Net weight: 1.49 kg
- Gross weight: 2.77 kg
- Rack or desktop installation
