Description
- 4 IP channels
- Video compression: Smart H.265+, H.265, Smart H.264+, H.264
- Simultaneous HDMI (4K) and VGA (1080P) video outputs
- Output division: 1, 4
- 1 audio input / 1 RCA audio output
- Audio compression: PCM, G.711a, G.711u, G726
- Recording resolution: 12MP, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP, 720P, D1, CIF, QCIF
- Bandwidth: 80 Mbps input, 80 Mbps for recording, 60 Mbps output
- Decoding capacity with AI disabled:
- 1 channel @ 12MP (30 fps)
- 2 channels @ 8MP (30 fps)
- 3 channels @ 5MP (30 fps)
- 4 channels @ 4MP (30 fps)
- AI-enabled decoding capacity:
- 1 channel @ 12MP (30 fps)
- 1 channel @ 8MP (30 fps)
- 2 channels @ 5MP (30 fps)
- 3 channels @ 4MP (30 fps)
- General, motion detection, intelligence, alarm, and alarm recording modes
- Video sensor alarm, privacy mask alarm, video loss, scene change, PIR alarm, external camera
- Artificial intelligence from smart cameras: Perimeter protection (4 channels), face detection (4 channels), face recognition (4 channels), SMD Plus (4 channels)
- Artificial intelligence in the recorder: SMD Plus (4 channels)
- Playback up to 4 channels
- Internal capacity for 1 SATA hard drive up to 20 TB (sold separately)
- RJ45 Fast Ethernet network port (10/100 Mbps)
- Network protocols: HTTP, HTTPS, TCP/IP, IPv4, UDP, NTP, DHCP, DNS, SMTP, UPnP, IP filter, DDNS, alarm server, IP search (supports IP cameras, DVRs, NVS, etc.), P2P, auto-registration
- ONVIF 22.12 (T/S/G), CGI and SDK support
- Compatible with web browsers
- Compatible with Android and iOS devices
- Access to local network server and Internet
- Ability to limit user access to cameras in local and/or remote mode
- Can be remotely controlled via a Joystick keyboard connected via TCP/IP
- Email sending with attached photo in case of alarm
- Sending to programmed FTP or alarm
- Ability to send an alarm and connect to a video surveillance reception software
- Possibility of fixed or dynamic IP via Dyndns, NoIP, DDNS Evolution, etc. service
- Communication ports: 2 USB 2.0 ports
- 4 PoE+ ports (10/100Mbps, 802.3 af/at)
- 36W total PoE power
- Power supply: 53V DC, 1.22A
- Power consumption: ≤10W (without disks)
- Storage temperature: -20°C ~ +60°C
- Operating temperature: -10°C ~ +55°C
- Relative humidity 10%~93%.
- Dimensions: 204.6 (W) x 45.6 (H) x 206.4 mm
- Net weight: 500 g
- Gross weight: 1.38 kg
- Tabletop installation
