Description
- 5 technologies: IP, HDCVI, HDTVI, AHD, and analog CVBS cameras with automatic signal recognition
- 8 BNC channels up to 8MP/4K (BNC inputs can be converted to IP)
- Up to 16 IP channels (8 IP channels by default + 8 analog channels converted to IP channels)
- Video compression: AI, Smart H.265+, H.265, Smart H.264+, H.264
- HDMI (4K) and VGA (1080P) video outputs with simultaneous/heterogeneous configurable video sources.
- Output split: 1, 4, 8, 9 (IP mode disabled); 1, 4, 8, 9, 16 (IP mode enabled)
- 1 RCA audio input / 1 RCA audio output
- 8 audio inputs via coaxial cable
- Audio compression: G.711a, G.711u, PCM
- Recording resolution:
- CVI: 8MP/4K (25/30 fps), 6MP (20 fps), 5MP (20/25 fps), 4MP (25/30 fps), 1080P (25/30 fps), 720P (25/30/50/60 fps)
- TVI: 8MP/4K (15 fps), 5MP (20 fps), 4MP (25/30 fps), 3MP (25/30 fps), 1080P (25/30 fps), 720P (25/30 fps)
- AHD: 8MP/4K (15 fps), 5MP (20 fps), 4MP (25/30 fps), 3MP (25/30 fps), 1080P (25/30 fps), 720P (25/30 fps)
- Bandwidth: 128 Mbps input, 128 Mbps recording, and 128 Mbps output (when IP mode is enabled, AI functions such as IVS, SMD, or face detection are disabled).
- Main stream: 8MP/4K (1~15 fps), 6MP (1~20 fps), 5MP, 4K-N, 4MP, 3MP, 4M-N, 1080P, 720P, 960H, D1, CIF (1~25/30 fps)
- Substream: 960H (1~15 fps), D1/CIF (1~25/30 fps)
- Recording modes: general, video detection, IVS, alarm, POS
- Playback up to 8 channels
- Perimeter protection: 2 channels, 10 IVS rules per channel
- Face detection: 2 channels, each channel detects up to 12 faces
- Face recognition: 2 channels, up to 10 databases and 20,000 facial images
- SMD Plus: 8 channels, human and vehicle classification
- Internal capacity for 1 SATA hard drive up to 16TB (sold separately)
- Multilingual on-screen menu with a new improved GUI
- Possibility to update the DAHUA camera firmware from the recorder itself
- Software and hardware watchdog
- Watermark to preserve video integrity
- RJ45 Gigabit Ethernet network port (10/100/1000 Mbps)
- Supports ONVIF 22.12 (T/S/G), CGI and SDK
- Remote access from a web browser and an iPhone, iPad or Android device (EVO and TTS App)
- Email sending with attached photo in case of alarm
- Sending to an FTP scheduled or on alarm
- Possibility of sending an alarm and being connected to an alarm reception software (C.R.A.) via the free software AlarmSpace
- Possibility of fixed or dynamic IP via the DDNS Evolution service
- Communication ports: 1 USB 2.0 port, 1 USB 3.0 port, 1 RS485 port (for PTZ control)
- Power supply: 12V DC, 3A
- Power consumption: <15W (without drives)
- Operating temperature: -10°C ~ +55°C
- Relative humidity 10%~90%.
- Dimensions: 325 (W) 55 (H) x 254.2 mm
- Net weight: 1.2 kg
- Gross weight: 1.9 kg
- Rack or desktop installation
