Description
- 8 megapixel 1/1.8 inch Sony Starvis™ CMOS image sensor
- Smart H.265+, Smart H.264+, H.265, H.264, and MJPEG video compression
- Resolution: 8MP (3840x2160), 4MP (2560x1440), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
- Stream 1: 8MP, 4MP, 1080P, 1.3MP, 720P (1~25/30 fps)
- Stream 2: D1, VGA, CIF (1~25/30 fps)
- Stream 3: 1080P, 1.3MP, 720P (1~25/30 fps)
- Day/night mode with removable mechanical filter
- 0.005 lux F1.4 (color), 0.0005 lux F1.4 (B/W), 0 lux IR On
- Smart IR: 10 IR LEDs, up to 500 meters
- 48X optical zoom: 6.25 ~ 300 mm
- Viewing angle: 64.6°~1.5°(H), 35.6°~1°(V), 68.5°~2°(D)
- Auto, semi-auto, and manual focus
- 16X digital zoom
- Image modes: BLC, HLC, WDR 120dB, 2D/3D-NR, optical defog
- White balance with 8 modes
- Automatic and manual gain control
- Video sensor and Region of Interest (ROI) support
- Privacy masking up to 24 zones with 8 zones on one screen
- Perimeter protection: line crossing, intrusion, fence climbing, loitering detection, abandoned/missing object, rapid movement, parking detection, person gathering, vehicle/person alarm classification.
- Face recognition
- Built-in auto tracking
- Video metadata: Supports image capture and attribute extraction of human body, human face, motorized and non-motorized vehicles.
- Horizontal positioner: 0° ~ 360° continuous
- Vertical positioner: -20° ~ 90°
- Manual speed: 0.1° ~ 240°/sec (H), 0.1° ~ 100°/sec (V)
- Preset speed: 200°/sec (H), 60°/sec (V)
- 300 presets, DH-SD and Pelco-D/P protocols with auto recognition
- 8 tours (up to 32 presets per tour)
- 5 patterns and 5 scans
- RS485 port
- 1 audio input / 1 audio output
- 7 alarm inputs / 2 alarm outputs
- BNC video output
- MicroSD card slot up to 512GB (card not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: FTP, RTMP, IPv6, Bonjour, IPv4, DNS, RTCP, PPPoE, NTP, RTP, 802.1x, HTTPS, SNMP, TCP/IP, DDNS, UPnP, NFS, ICMP, UDP, IGMP, SMB, HTTP, SSL, DHCP, SMTP, QoS, RTSP, ARP
- ONVIF support (S/G/T), CGI, SDK
- Up to 20 users
- Compatible with IOS and Android devices
- Compatible with IE, Chrome, Firefox, and Safari browsers
- Power supply: 36V DC, 2.23A (±25%) / Hi-PoE
- Power consumption: 18W (basic), 33W (illuminator + positioner)
- Operating temperature: -40°C ~ +70°C
- Relative humidity ≤95%.
- IP67 degree of protection
- 8KV lightning protection
- Includes a lens wiper
- Dimensions: Ø262 x 442 (H) mm
- Gross weight: 12.5 kg
- Net weight: 10.3 kg
- Includes wall mount and power supply
