Description
- 1/1.7" 12-megapixel CMOS sensor
- Compression formats: Smart H.265+, Smart H.264+, H.265, AI H.264, H.264, MJPEG
- Digital resolution: 12MP (4000x3000), 8MP (3840x2160), 6MP (3072x2048), 5MP (3072x1728, 2592x1944), 4MP (2688x1520), 3MP (2048x1535, 2304x1296), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), CIF (352x288)
- Stream 1: 12MP (1~25/30 fps)
- Stream 2: 1080P (1~25/30 fps)
- Stream 3: 1080P (1~25/30 fps)
- Stream 4: 1080P (1~25/30 fps)
- Stream 5: D1 (1~25/30 fps)
- Day/night mode with removable mechanical filter (ICR)
- Smart IR: 4 leds, 60 meters
- 0.0009 lux F1.6 (color), 0.0005 lux F1.6 (B/W), 0 lux IR On
- Motorized 2.7 ~ 12 mm lens
- Viewing angle: 106°~45°(H), 77°~34°(V), 140°~56°(D)
- Imaging modes: BLC, HLC, digital WDR, SSA, 3D-NR, EIS (image stabilizer), Mirror, Defog
- White balance with 6 modes
- Automatic gain control
- Supports 4-zone video sensor, 4 regions of interest (ROI), and 8-zone privacy mask
- Smart detection of abandoned or missing objects
- ePTZ function
- Perimeter protection: line crossing detection, intrusion detection, fast movement detection (all three functions allow classifying people and vehicles), loitering detection, crowd gathering, and parking detection
- Face detection with extraction of 6 attributes and 8 facial expressions
- Face recognition: the system includes a general mode of face detection, optimization and management of face databases, as well as a counting mode with a customer counter function and specific face filtering
- People counting with line crossing detection and entry into specific areas, generating daily, monthly, and annual exportable reports; it also has a queue management function and allows configuring up to 4 rules for counting and queue management functions
- Heat map
- PPE detection (Personal Protective Equipment): triggers alarms depending on whether the detected object meets all configured characteristics, including helmets, caps, uniforms, masks, gloves, shoe covers, shoes, safety vests, and safety belts
- ANPR: License plate recognition at speeds up to 60 km/hour with vehicle tracking and snapshot capture, identification of vehicle attributes (such as plate number, type, and color), detection of seat belt use, smoking or talking on the phone, supports up to 10,000 blacklisted and whitelisted records
- Parking space management system to manage outdoor and planned parking spaces
- Video metadata
- 1 RCA audio input / 1 RCA audio output
- 3 alarm inputs / 2 alarm outputs
- 1 BNC video output
- 1 RS485 port
- MicroSD card slot up to 512GB (not included)
- Network interface: RJ45 (10/100/1000 Base-T)
- Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP, P2P
ONVIF support (Profile S/G/T), CGI, SDK, API - Up to 20 users
- Remote viewing via browsers
- Management software Smart PSS Lite, DSS, DMSS, Smart PSS Lite
- Compatible with IOS and Android mobile devices
- Power supply: 12V DC / 24V AC / PoE+ (802.3at) / ePoE
- Maximum power consumption: 18.2W (12V), 24.2W (24V), 24.3W (PoE)
- Storage temperature: -40°C ~ +65°C
- Storage relative humidity: 10% ~ 95%
- Operating temperature -40°C ~ +65°C
- Operating relative humidity: <95%
- IP67 protection rating
- IK10 vandal protection
- Metal and plastic casing
- Dimensions: 134.2 (W) x 135.1 (H) x 345.6 mm
- Gross weight: 2.73 kg
- Net weight: 1.65 kg
- 3 AXIS: 0°~355°(PAN), 0°~90°(TILT), 0°~360°(ROTATION)
