Description
- 1/2.8" 2-megapixel Sony Starvis™ CMOS image sensor
- Smart H.265+, Smart H.264+, H.265, H.264 and MJPEG video compression
- Resolution: 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), CIF (352x288)
- Stream 1: 1080P, 1.3MP, 720P (1~25/30 fps)
- Stream 2: D1, CIF (1~25/30 fps)
- Stream 3: 1080P, 1.3MP, 720P (1~25/30 fps)
- Day/night mode with removable mechanical filter
- 0.005 lux F1.6 (color), 0.0005 lux F1.6 (B/W), 0 lux IR On
- Smart IR: 4 IR LEDs, up to 100 meters
- 25X optical zoom: 4.8 ~ 120 mm
- Viewing angle: 58.5°~2.8°(H), 33.2°~1.5°(V), 67.5°~3.2°(D)
- Auto, semi-auto and manual focus
- Automatic aperture control
- 16X digital zoom
- Image modes: BLC, HLC, WDR 120dB, 2D/3D-NR, EIS (image stabilizer), digital defogging
- White balance with 8 modes
- Automatic and manual gain control
- Video sensor support and regions of interest (ROI)
- Privacy masking up to 24 zones with 8 zones on a single screen
- Perimeter protection: line crossing, intrusion, fence climbing, loitering detection, abandoned/missing object, fast movement, parking detection, crowd gathering, vehicle/person alarm classification
- Face detection with extraction of 6 attributes and 8 expressions
- Smart motion detection SMD 4.0
- Horizontal positioner: 0° ~ 360° continuous
- Vertical positioner: -15° ~ 90°, with 180 auto-flip
- Manual speed: 0.1° ~ 200°/sec (H), 0.1° ~ 120°/sec (V)
- Preset speed: 240°/sec (H), 200°/sec (V)
- 300 presets, DH-SD and Pelco-D/P protocols with auto-recognition
- 8 tours (up to 32 presets per tour)
- 5 patterns and 5 scans
- 1 audio input / 1 audio output
- 2 alarm inputs / 1 alarm output
- MicroSD card slot up to 512 GB (card not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: FTP, RTMP, IPv6, Bonjour, IPv4, DNS, RTCP, PPPoE, NTP, RTP, 802.1x, HTTPS, SNMP, TCP/IP, DDNS, UPnP, NFS, ICMP, UDP, IGMP, HTTP, SSL, DHCP, SMTP, QoS, RTSP, ARP
- ONVIF (S/G/T), P2P, RTMP, CGI, SDK support
- Compatible with iOS and Android devices
- Compatible with IE, Chrome and Firefox browsers
- Up to 20 users
- DSS, DMSS management software
- Power supply: 12V DC, 3A (±25%) / PoE+ (802.3at)
- Power consumption: 9W (basic), 20W (maximum)
- Operating conditions: -40°C ~ +70°C, humidity <95%
- IP66 protection rating
- 6KV lightning resistant
- Dimensions: Ø160 x 270.4 (H) mm
- Gross weight: 3.9 kg
- Net weight: 2.4 kg
- Wall mount included
- Power supply not included
