Description
- 5 megapixel 1/2.7" CMOS sensor
- Compression formats: AI H.265, AI H-264, Smart H.265+, Smart H.264+, H.265, H.264, MJPEG
- Digital resolution: 5MP (2880x1620, 2960x1668), 4MP (2688x1520), 3.6MP (2560x1440), 3MP (2048x1536, 2304x1296), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
- Stream 1: 4MP (1~20 fps), 4MP (1~25/30 fps)
- Stream 2: D1 (1~25/30 fps)
- Stream 3: 1080P (1~25/30 fps)
- Day/night mode with removable mechanical filter
- Smart IR: 2 IR LEDs, 30 meter range
- 0.005 lux F1.4 (color), 0.0005 lux F1.4 (B/W), 0 lux IR On
- 2.8mm fixed lens
- Viewing angle: 111°(H), 58°(V), 132°(D)
- Imaging modes: BLC, HLC, WDR 120dB, 3D-NR, AFSA, Mirror, Defog
- White balance with 6 modes
- Automatic gain control
- Supports 4-zone video sensor, 4 regions of interest (ROI) and 4-zone privacy mask
- Perimeter protection with cross-line detection and intrusion detection (both modes support human and vehicle classification)
- Built-in microphone
- 1 RCA audio input / 1 RCA audio output
- 1 alarm input / 1 alarm output
- MicroSD card slot up to 256 GB (not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: IPv4, IPv6, HTTP; TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP
- ONVIF (Profile S/G/T), CGI, P2P, Milestone, Genetec, SDK, API support
- Up to 20 users
- Remote viewing via IE11, Chrome and Firefox browsers
- Smart PSS, DSS, DMSS management software
- Compatible with iOS and Android mobile devices
- Power supply: 12V DC / PoE (802.3af)
- Maximum power consumption: 5.9W (12V) / 7.2W (PoE)
- Storage temperature: -40°C ~ +60°C
- Operating temperature: -40°C ~ +60°C (-40°F ~ +140°F)
- Relative humidity: <95%.
- IP67 protection rating
- IK10 vandal protection
- Metal casing
- Dimensions: Ø111 x 64.8 (H) mm
- Gross weight: 540 g
- Net weight: 423 g
- 3AXIS: 0°~355°(PAN), -20°~70°(TILT), 0°~355°(Rotation)
