Description
- Uncooled VOx focal plane sensor
- Effective pixels: 256 x 192
- Pixel size: 12 µm
- Thermal sensitivity (NETD): <40mK
- Spectrum: 8 ~14 µm
- Focal length (thermal): 3.5 mm
- Viewing angle (thermal): 50.6°(H), 37.8°(V)
- Effective distance for people:
- Detection: 146 metres
- Recognition: 38 metres
- Identification: 19 metres
- Effective distance for vehicles:
- Detection: 449 metres
- Recognition: 110 metres
- Identification: 56 metres
- 16X digital zoom
- Digital detail enhancement
- Automatic and manual gain control
- 2D and 3D noise reduction
- 18 colour palettes
- 3 fusion modes: warm colours, cold colours, iron red
- Image sensor (visible camera) 1/2.7 4 megapixel CMOS
- Effective pixels: 2336 x 1752
- Infrared illumination of ≥30 metres
- Minimum illumination: 0.05 lux (colour) / 0.005 lux (B/W) / 0 lux IR On
- Focal length (visible optics): 4 mm
- Viewing angle (visible optics): 71.2°(H), 52°(V)
- Day/night mode with removable mechanical filter.
- Imaging modes: BLC, HLC, digital WDR, 2D/3D-NR, exposure compensator.
- White balance with 7 modes
- Automatic and manual gain control
- Support for Regions of Interest (ROI)
- Video compression H.265, H.264, MJPEG
- Visible camera resolution: 4MP (2336x1752), 1080P (1920x1080), 720P (1280x720), D1 (704x576), CIF (352x288), 256x192
- Thermal stream 1: 1.3MP (default), XVGA, VGA, 256x192 (1~25 ips)
- Thermal stream 2: 256x192 (default), VGA (1~25 ips)
- Visible stream 1: 4MP (default), 1080P, 720P, D1 (1~25 ips)
- Visible stream 2: 720P, D1, CIF (default) (1~25 ips)
- IVS detection: cross line detection, intrusion detection
- Advanced detection features: fire and alarm detection, cold and hot spot tracking, people and vehicle classification, smoke detection, call detection
- Supports 12 simultaneous measurement rules (12 points, 12 lines, 12 regions)
- Low temperature range: -20°C ~ +150°C
- High temperature range: 0°C ~ +550°C
- Temperature accuracy: ±2°C, ±2% / operating temperature -20°C ~ +50°C
- Audio compression G.711A, G.711Mu and PCM
- 1 audio input / 1 audio output
- 1 alarm input / 1 alarm output
- RS485
- Ethernet RJ-45 (10/100M Base-T)
- Network protocols: HTTPS, HTTP, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, IPv4/v6, SNMP, QoS, UPnP, NTP
- Onvif and CGI support
- Up to 10 users
- Compatible with IE8, Chrome42, Firefox42 browsers
- microSD card slot up to 256 GB (card not included)
- Power supply: 12VDC (±20%) / PoE
- Maximum power consumption: 14W (12V DC) / 20W (PoE)
- Storage temperature: -30°C ~ +70°C
- Operating temperature: -30°C ~+50°C
- Relative humidity: <95%.
- IP67 protection rating
- Dimensions: 90.4 (W) x 90.1 (H) x 205.5 mm
- Weight: 900 g
