Description
- 1/2.8" 2-megapixel CMOS sensor
- Compression formats: AI H.265, Smart H.265+, Smart H.264+, H.265, AI H.264, H.264, MJPEG
- Digital resolution: 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
- Stream 1: 1080P (1~25/30 fps)
- Stream 2: D1 (1~25/30 fps)
- Stream 3: 1080P (1~25/30 fps)
- Stream 4: 720P (1~25/30 fps)
- Day/night mode with removable mechanical filter (ICR)
- Smart IR: 1 LED, 50 meters
- 0.0007 lux F1.6 (color), 0.0004 lux F1.6 (B/W), 0 lux IR On
- 2.8 mm fixed lens
- Viewing angle: 106°(H), 56°(V), 127°(D)
- Imaging modes: BLC, HLC, WDR 120dB, SSA, 3D-NR, Mirror, Defog
- White balance with 6 modes
- Automatic gain control
- Supports 4-zone video sensor, 4 regions of interest (ROI), and 8-zone privacy mask
- Perimeter protection: cross-line detection, intrusion detection, fast motion detection (all three functions allow classification of people and vehicles), loitering detection, crowd gathering detection, and parking detection.
- Smart abandoned object detection, missing object detection
- SMD 3.0: fewer false alarms, greater detection distance
- Supports heat mapping
- Face detection with extraction of 6 attributes and 8 facial expressions
- People counting: multi-line people counting, generation, area people counting, and queue management.
- Video metadata
- Smart sound detection
- Built-in microphone
- 1 RCA audio input / 1 RCA audio output
- 1 alarm input / 1 alarm output
- MicroSD card slot up to 512 GB (not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP, P2P
- Supports ONVIF (Profile S/G/T), CGI, SDK, API
- Up to 20 users
- Remote viewing via browsers
- Management software: Smart PSS Lite, DSS, DMSS, Smart PSS Lite
- Compatible with iOS and Android mobile devices
- Power supply: 12V DC / PoE (802.3af) / ePoE
- Maximum power consumption: 6.2W (12V), 8.3W (PoE)
- Storage temperature: -40°C ~ +60°C
- Storage relative humidity: 10% ~ 95%
- Operating temperature: -30°C ~ +60°C
- Operating relative humidity: <95%.
- IP67 protection rating
- Metal casing
- Dimensions: 70.5 (W) x 66.4 (H) x 192.7 mm
- Gross weight: 780 g
- Net weight: 590 g
- 3 AXIS: 0°~360°(PAN), 0°~90°(TILT), 0°~360°(ROTATION)
