Description
- 1/2.8" 4-megapixel Sony Starvis™ CMOS image sensor
- Smart H.265+, Smart H.264+, H.265, H.264, and MJPEG video compression
- Resolution: 4MP (2560x1440), 3MP (2304x1296), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
- Stream 1: 4MP, 3MP, 1080P, 1.3MP, 720P (1~25/30 fps)
- Stream 2: D1, VGA, CIF (1~25/30 fps)
- Stream 3: 720P, CIF (1~25/30 fps)
- Day/night mode with removable mechanical filter
- 0.005 lux F1.6 (color), 0.0005 lux F1.6 (B/W), 0 lux IR on
- Smart IR: 6 IR LEDs, up to 100 meters
- 25X optical zoom: 5 ~ 125 mm
- Viewing angle: 51.9°~3°(H), 39.7°~2.2°(V), 63.1°~3.7°(D)
- Auto, semi-auto, and manual focus
- Automatic, manual, and fixed iris control
- 16X digital zoom
- Image modes: BLC, HLC, WDR 120dB, 2D/3D-NR, EIS, Digital Defog
- White balance with 8 modes
- Automatic and manual gain control
- Supports video sensor and regions of interest (ROI)
- Privacy masking up to 24 zones with 8 zones on a single screen
- Perimeter protection: line crossing, intrusion, fence climbing, loitering detection, abandoned/missing object, fast movement, parking detection, crowd gathering, vehicle/person alarm classification.
- Face detection and SMD
- Auto tracking available
- Horizontal positioner: 0° ~ 360° continuous
- Vertical positioner: -5° ~ 90°, with 180° auto flip
- Manual speed: 0.1° ~ 240°/sec (H), 0.1° ~ 160°/sec (V)
- Preset speed: 240°/sec (H), 160°/sec (V)
- 300 presets, DH-SD protocol
- 8 tours (up to 32 presets per tour)
- 5 patterns and 5 scans
- 1 audio input / 1 audio output
- 2 alarm inputs / 1 alarm output
- MicroSD card slot up to 512GB (card not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: FTP, RTMP, IPv6, Bonjour, IPv4, DNS, RTCP, PPPoE, NTP, RTP, 802.1x, HTTPS, SNMP, TCP/IP, DDNS, UPnP, NFS, ICMP, UDP, IGMP, HTTP, SSL, DHCP, SMTP, QoS, RTSP, ARP, SAMBA
- Supports ONVIF S/G/T, P2P, CGI
- Compatible with iOS and Android devices
- Compatible with IE, Chrome, Firefox, Safari browsers
- Up to 20 users
- DMSS, DSS Pro management software
- Power supply: 12V DC, 2A / PoE+ (802.3at)
- Power consumption: 9.5W (basic), 21.5W (maximum)
- Operating conditions: -40°C ~ +65°C, humidity <95%
- IP66 protection rating
- 6KV lightning resistant
- Dimensions: Ø171.1 x 170.4 (H) mm
- Gross weight: 3.2 kg
- Net weight: 2.5 kg
- Power supply included
