Description
- 1/2.7" 4-megapixel CMOS sensor
- Compression formats: Smart H.265+, H.265, Smart H.264+, H.264, MJPEG
- Digital resolution: 5MP (2880x1620), 4MP (2688x1520), 4MP (2560x1440), 3MP (2048x1536), 3MP (2304x1296), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
- Stream 1: 5MP (1~20 fps), 4MP (1~25/30 fps)
- Stream 2: D1 (1~25/30 fps)
- Stream 3: 1080P (1~25/30 fps)
- Day/night mode with removable mechanical filter
- Smart IR: 2 LEDs, 20-meter range
- 0.01 lux F2.0 (color), 0.001 F2.0 (B/W), 0 lux IR On
- 2.1 mm fixed lens
- Lens Distortion Correction (LDC) enabled by default
- Viewing angle with LDC mode enabled: 170°(H), 75°(V), 175°(D)
- Viewing angle with LDC mode disabled: 180°(H), 78°(V), 180°(D)
- Image modes: BLC, HLC, WDR 120dB, 3D-NR, Mirror, Defog
- White balance with 6 modes
- Automatic and manual gain control
- Supports 4-zone video sensor, 4 Regions of Interest (ROI), and 4-zone privacy masking
- Perimeter protection with cross-line detection and intrusion detection (both modes support human/vehicle classification)
- SMD 3.0: fewer false alarms, longer detection distance
- Built-in microphone
- 1 RCA audio input / 1 RCA audio output
- 1 alarm input / 1 alarm output
- MicroSD card slot up to 256 GB (not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP
- ONVIF (Profile S/G/T), CGI, P2P, SDK, API support
- Up to 20 users
- Remote viewing via IE, Chrome, and Firefox browsers
- Smart PSS, DSS, DMSS management software
- Compatible with iOS and Android mobile devices
- Power supply: 12V DC / PoE
- Maximum power consumption: 3.1W (12V) / 5.3W (PoE)
- Storage temperature from -40°C ~ +60°C
- Operating temperature from -40°C ~ +60°C
- Relative humidity: <95%
- IP67 protection rating
- Metal casing
- Dimensions: 90.7 (L) x 90.4 (H) x 249.3 mm
- Weight: 820 g
- 3AXIS: 0°~360°(PAN), 0°~90°(TILT), 0°~360°(Rotation)
