Description
- 1/1.8" 4-megapixel CMOS sensor
- Compression formats: Smart H.265+, H.265+, Smart H.264+, H.264, MJPEG
- Digital resolution: 4MP (2688x1520), 3MP (2304x1296), 1080P (1920x1080), 1.3MP (1280x960), 720P (1280x720), D1 (704x576), VGA (640x480), CIF (352x288)
- Stream 1: 4MP (1~50/60 fps)
- Stream 2: D1 (1~25/30 fps)
- Stream 3: 1080P (1~25/30 fps)
- Stream 4: 1080P (1~25/30 fps)
- Stream 5: D1 (1~25/30 fps)
- Day/night mode with removable mechanical filter
- Smart IR: 4 leds, 120 meters
- 0.001 lux F1.6 (color), 0.0002 lux F1.6 (B/W), 0 lux IR On
- Motorized lens 8 ~ 32 mm
- Viewing angle: 41°~15°(H), 22°~9°(V), 48°~18°(D)
- Imaging modes: BLC, HLC, WDR 140dB, 3D-NR, Mirror, Defog, EIS
- White balance with 6 modes
- Automatic and manual gain control
- Supports 4-zone video sensor, 4 Regions of Interest (ROI), and 4-zone privacy mask
- Intelligent Video Detection (IVS): abandoned or lost object detection
- Perimeter protection with line crossing detection, intrusion detection, fast motion detection (all three modes support person/vehicle classification), loitering detection, people gathering detection, and parking detection
- Face detection, face recognition, and face and body detection
- People counting: count people entering/exiting and the number of people passing; display and generate annual/monthly/weekly/daily reports; assist in counting people in an area and establish 4 rules
- 1 RCA audio input/output
- 3 alarm inputs / 2 alarm outputs
- RS485 port
- MicroSD card slot up to 256 GB (not included)
- Network interface: RJ45 (10/100/1000 Base-T)
- Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP
- ONVIF (Profile S/G/T), CGI, P2P, Milestone, SDK, API support
- Up to 20 users
- Remote viewing via IE9, Chrome 42 and Firefox 48.0.2 browsers
- Smart PSS, DSS, DMSS management software
- Compatible with iOS and Android mobile devices
- Power supply: 12V DC / 24V AC / PoE (802.3at)
- Power consumption: 16.8W (12V), 20.7W (24V), 21.3W (PoE)
- Storage temperature -40°C ~ +65°C (-40°C ~ +65°C)
- Operating temperature from -40°C ~ +65°C
- Relative humidity: <95%.
- IP67 protection rating
- IK10 vandal protection
- Metal and plastic casing
- Dimensions: 138.3 (W) x 134 (H) x 340.1 mm
- Weight: 1.54 kg
