Description
- Dual 1/1.8" 4-megapixel CMOS sensor
- Compression formats: Smart H.265+, Smart H.264+, H.265, H.264, MJPEG
- Digital resolution: 8MP (4096x1800), 6.5MP (3840x1680), 4MP (3840x1080), 4MP (2880x1264), 1.6MP (1920x832), 0.7MP (1280x560), 0.5MP (1024x452)
- Stream 1: 4096x1800 (1~25 fps without WDR, 1~20 fps with WDR)
- Stream 2: 1024x452 (1~25 fps without WDR, 1~20 fps with WDR)
- Stream 3: 1920x832 (1~25 fps without WDR, 1~20 fps with WDR)
- Day/Night mode
- Smart light: 4 warm light LEDs, 40 meters
- 0.0005 lux F1.0 (color), 0.0002 lux F1.0 (B/W), 0 lux white light on
- 3.6 mm fixed lens
- Viewing angle: 180°(H), 48°(V)
- Imaging modes: BLC, HLC, WDR 140dB, 3D-NR, Defog
- White balance with 6 modes
- Automatic and manual gain control
- Supports 4-zone video sensor, 4 regions of interest (ROI), and 4-zone privacy mask.
- Intelligent Video Detection (IVS): abandoned/lost object detection, heat mapping.
- Perimeter protection with line crossing detection, intrusion detection, fast motion detection (all three modes support person/vehicle classification), loitering detection, people gathering detection, and parking detection.
- People counting: count people entering/exiting and the number of people passing; display and generate annual/monthly/weekly/daily reports; assist in counting people in an area and establish 4 rules.
- Built-in microphone
- 1 RCA audio input / 1 output
- 1 alarm input / 1 alarm output
- MicroSD card slot up to 512 GB (not included)
- Network interface: RJ45 (10/100 Base-T)
- Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP, Bonjour
- ONVIF (Profile S/G/T), CGI, Milestone, SDK support
- Up to 20 users
- Remote viewing via IE8 and later, Chrome, and Firefox browsers
- Smart PSS, DSS, DMSS management software
- Compatible with iOS and Android devices
- Power supply: 12V DC (±30%) / PoE+ (802.3at) / ePoE
- Maximum power consumption: 10.8W (12V), 11.8W (PoE)
- Storage temperature -40°C ~ +60°C
- Operating temperature: -40°C ~ +60°C
- Relative humidity: <95%.
- IP67 protection rating
- Metal and plastic casing
- Dimensions: 128.2 (L) x 120 (H) x 301.2 mm
- Weight: 1.4 kg
- 3AXIS: 0°~360° (Pan), 0°~90° (Tilt), 0°~360° (Rotation)
