Description
Specifications
- 2 megapixel CMOS sensor
- Digital resolution: 1080P (1920x1080), 960H (960x576)
- Frame rate: 25 fps @ 1080P (CVI/TVI/AHD), 25 fps @ 960H (CVBS)
- 4-in-1 output switchable by DIP switch
- Day/night mode with removable mechanical filter
- 0.001 lux F1.6 (color) / 0 lux with IR on
- Smart IR: 2 IR LEDs, 30 meters
- 2.8mm fixed lens
- Viewing angle: 109°(H), 58°(V), 127°(D)
- Image modes: BLC, HLC, WDR 130dB, 3D-NR, Mirror
- Automatic and manual white balance
- Automatic and manual gain control
- Supports 8-zone privacy mask
- Includes microphone
- Power supply: 12V DC (±30%)
- Consumption: 3W (12V)
- Storage temperature -40°C ~ +60°C
- Operating temperature -40°C ~ +60°C
- Relative humidity: <95% (non-condensing)
- IP67 protection rating
- Metal housing
- Dimensions: 69.7 (W) x 70 (H) x 161.3 mm
- Weight: 330g
- 3 AXES: 0°~360°(PAN), 0°~90°(TILT), 0°~360°(Rotation)
