- 5 technologies: IP, HDCVI, HDTVI, AHD and analog CVBS cameras with automatic signal recognition
- 16 BNC channels up to 5MP (BNC inputs can be converted to IP)
- 8 IP channels at 6MP (added to BNC inputs)
- Video compression: AI, H.265+, H.265, H.264+, H.264
- HDMI (4K) and VGA (up to 1080P) video outputs
- Output division: 1, 4, 8, 9, 16 (IP mode disabled); 1, 4, 8, 9, 16, 25 (IP mode enabled)
- Two-way audio: 1 RCA input / 1 RCA audio output
- 16 audio inputs via coaxial cable
- Audio compression: G.711a, G.711u, PCM
- Recording resolution: 6MP(IP), 5M-N, 4M-N, 1080P, 1080N, 720P, 960H, D1, CIF
- Maximum incoming bandwidth of 128 Mbps
- Main stream: 5M-N (1~10fps), 4M-N/1080P (1~15fps), 1080N/720P/960H/D1/CIF (1~25fps)
- Sub stream: D1/CIF (1~15 fps)
- Recording modes: manual, scheduled, video detection, video loss, tampering, alarm, stop
- Playback up to 16 channels
- Perimeter protection: 2 channels
- Face detection: 2 channels, each channel detects up to 12 faces, up to 10 databases and 20,000 face images
- SMD Plus: 16 channels, person/vehicle classification
- Internal capacity for 1 SATA hard drive up to 16TB (sold separately)
- Multilingual on-screen menu with improved new GUI
- Possibility to update DAHUA camera firmware from the recorder itself
- Software and hardware watchdog
- Watermark to preserve video integrity
- RJ45 Gigabit Ethernet network port (10/100/1000 Mbps)
- ONVIF 16.12 and CGI compliance
- Remote access from a web browser and iPhone, iPad, Android devices (App EVO and TTS)
- Email sending with attached photo in alarm
- Send to FTP scheduled or in alarm
- Possibility to send an alarm and be connected to the alarm receiving software (C.R.A.) via the free AlarmSpace software
- Possibility of fixed or dynamic IP via the DDNS Evolution service
- Communication ports: 1 USB 2.0 port, 1 USB 3.0 port, 1 RS485 port (for PTZ control)
- Power supply: 12V DC, 2A (<12W, not including drives)
- Storage temperature -20°C ~ +70°C
- Operating temperature -10°C ~ +55°C
Relative humidity 10% ~ 90% - Dimensions: 260 (W) 47.6 (H) x 237.6 mm
- Weight: 1.17 kg
- Desktop installation
